ComAp IG-NT Reference Manual page 247

Binary input: PulseCounter 4
Related FW 3.0
Description This is the input of the PulseCounter #4 module. The module counts pulses at the
input and if the input pulses counter reaches value given by the setpoint
ConvCoefPulse4, the counter value
increased by 1 and input pulses conter is reset to 0. Both counter value and input
pulses counter are stored in the nonvolatile memory.
The PulseCounter modules are intended e.g. for connecting external energy or
fuel meters with pulse outputs.
N
OTE
Minimal pulse width as well as minimal pause between two succesive pulses is
100ms.
N
OTE
The counter value can be reset in the InteliMonitor statistics window.
N
OTE
Available in IS-NT only.
Binary input: Timer block 1
Related FW 3.0
Description This input is used to disable temporarily the output from the Timer channel #1.
N
OTE
See also the setpoint
N
OTE
See the chapter
Binary input: Timer block 2
Related FW 3.0
Description This input is used to disable temporarily the output from the Timer channel #2.
N
OTE
See also the setpoint
N
OTE
See the chapter
Binary input: Timer block 3
Related FW 3.0
This input is used to disable temporarily the output from the Timer channel #3.
Description
N
OTE
See also the setpoint
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
:
:
:
:
TimerChannel 1
:
Timers for more details about timers.
:
TimerChannel 2
:
Timers for more details about timers.
:
TimerChannel 3
PulseCounter 4 (in the group Statistic) is
and output TimerAct 1-4.
and output TimerAct 1-4.
and output TimerAct 1-4.
247
