The threshold for the protection is adjusted by setpoint
N
OTE
The generator voltage unbalance protection is created in the default archive using
the mechanism of universal analog protections. That means this setpoint is one
of general-purpose setpoints, which may be used for different purpose if the
protection is deleted from the configuration.
Setpoint: Gen I unbal
Group Gener protect
Range [units] 0 .. 200 [%]
Related FW 3.0
Description This setpoint adjusts the threshold level for the generator current unbalance
protection. The threshold is adjusted in % of the generator
protection is Breaker open and cool down type and is created in the default
archive as universal analog protection at the value Gen I unbal, which is
calculated as maximum difference between two phase currents.
The protection activates if the current unbalance gets over the threshold for time
longer than
N
OTE
The current unbalance protection is created in the default archive using the
mechanism of universal analog protections. That means this setpoint is one of
general-purpose setpoints, which may be used for different purpose if the
protection is deleted from the configuration.
Setpoint: Gen I unb del
Group Gener protect
Range [units] 0.0 .. 600.0 [s]
Related FW 3.0
Description This setpoint adjusts the delay for the generator current unbalance protection. The
threshold for the protection is adjusted by setpoint
N
OTE
The generator current unbalance protection is created in the default archive using
the mechanism of universal analog protections. That means this setpoint is one
of general-purpose setpoints, which may be used for different purpose if the
protection is deleted from the configuration.
Setpoint: Bus V unbal
Group Gener protect
Range [units] 0 .. 200 [%]
Related FW 3.0
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
:
Gen I unb del.
:
:
Gen V unbal.
nominal current. The
Gen I unbal.
