Setpoint: Dwell time
Group Sync/Load Ctrl
Range [units] 0.0 .. 25.0 [s]
Related FW 3.0
Force value YES
possible
Force value YES
possible
Description This setpoint adjusts the period of time that the phase angle difference must stay
within
respective breaker, which is actually beeing synchronized, is closed.
Setpoint: Freq gain
Group Sync/Load Ctrl
Range [units] 0.0 .. 200.0 [%]
Related FW 3.0
Description This setpoint adjusts the gain factor (P-factor) of the frequency control PI loop.
The integration factor (I-factor) for the frequency loop is adjusted by the setpoint
Freq
N
OTE
See the chapter
regulation loops and their adjustment.
Setpoint: Freq int
Group Sync/Load Ctrl
Range [units] 0 .. 100 [%]
Related FW 3.0
Description This setpoint adjusts the relative integration factor (I-factor) of the frequency
