address will be assigned to aviod address collision.
N
OTE
Address 1 is reccommended for standalone gen-sets.
N
OTE
If you are connecting to the gen-set remotely you have to adjust the proper
controller address in connection settings of the remote client (InteliMonitor,
GenConfig, Modbus client etc.)
N
OTE
Address of the controller is also used for Modbus communication via RS485 etc.
Address adjusted by this setpoint is therefore universal address of the controller.
Setpoint: RS232(1) mode
Group Comms settings
Range [units] DIRECT, MODEM (HW), MODEM (SW), MODBUS-DIRECT, MODBUS-
MDM(HW), ECU LINK [-]
Related FW 3.0
Description This setpoint selects the connection type for the serial port COM1.
See the diagram of all related terminals in the chapter Communication.
DIRECT
MODEM (HW)
MODEM (SW)
MODBUS
MODBUS-MDM(HW)
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
:
:
:
Available as RS232 in all controller types.
Available also as RS485 in the IG-NT if the external display bus is not
used. Selectable by the setpoint
BB, IG-NTC-BB, IS-NTC-BB and IS-NT - see
Connection to a local PC via RS232 or RS485 (with
internal or external converter) interface. Use this
option also for IG-IB connected via RS232 cable.
The internal RS485 converter is enabled/disabled by
the setpoint
Modem point-to-point connection to a remote PC
with hardware data flow control using signals
RTS/CTS. Full modem cable is required for this
option.
Modem point-to-point connection to a remote PC
with software data flow control. 3-wire cable (RX, TX,
GND) is sufficient for this option. Use this option only
if your modem does not provide RTS/CTS signals.
Modbus RTU connection in slave mode via RS232 or
RS485 (with internal or external converter) interface.
The internal RS485 converter is enabled/disabled by
the setpoint
speed is adjustable by the setpoint
RS232(1)MBCSpd. See the latest communication
guide for more information about MODBUS protocol.
Modbus RTU connection in slave mode via modem
RS485(1) conv. (not available in IG-NT-
RS485(1)
RS485(1) conv.
RS485(1) conv., the communication
conv.).
