ComAp IG-NT Reference Manual page 146

Description This setpoint adjusts the threshold level for the bus voltage unbalance protection.
The threshold is adjusted in % of the nominal generator voltage, which is either
BusNomV
FixVoltProtSel. The protection is created in the default archive as universal
analog protection at the value Bus V unbal, which is calculated as maximum
difference between two bus phase voltages.
The protection activates if the voltage unbalance gets over the threshold for time
longer than
N
OTE
Activation of the protection is only recorded into the history file, no other actions
are performed.
N
OTE
The voltage unbalance protection is created in the default archive using the
mechanism of universal analog protections. That means this setpoint is one of
general-purpose setpoints, which may be used for different purpose if the
protection is deleted from the configuration.
Setpoint: Bus V unb del
Group Gener protect
Range [units] 0.0 .. 600.0 [s]
Related FW 3.0
Description This setpoint adjusts the delay for the bus voltage unbalance protection. The
threshold for the protection is adjusted by setpoint
N
OTE
The bus voltage unbalance protection is created in the default archive using the
mechanism of universal analog protections. That means this setpoint is one of
general-purpose setpoints, which may be used for different purpose if the
protection is deleted from the configuration.
Group: Power management
Setpoint: Pwr Management
Group Pwr Management
Range [units] DISABLED, ENABLED [-]
Related FW 3.0
Force value YES
possible
Description This setpoint is used to enable/disable the
particular controller.
If the function is disabled the start and stop of the gen-set is performed only
according to the position of the binary input
the gen-set is running and vice versa.
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
or BusNomVph-ph, depending on the position of the setpoint
Bus V unb del.
:
:
:
Bus V unbal.
power management function in the
Sys start/stop, i.e. if the input is active
146
