ComAp IG-NT Reference Manual page 170

Related FW 3.0
Force value YES
possible
Description This setpoint adjusts the initial level for the AVRi output. This level is present on
the output if no regulation loop is active.
N
OTE
The resulting voltage at the input of the AVR also depends on position of the
trimmer at the AVRi module.
Setpoint: VS gain
Group Volt/PF ctrl
Range [units] 0.0 .. 200.0 [%]
Related FW 3.0
Description This setpoint adjusts the gain factor (P-factor) of the VAr-sharing PI loop. The
integration factor (I-factor) for the VAr-sharing loop is adjusted by the setpoint
int.
N
OTE
See the chapter
regulation loops and their adjustment.
Setpoint: VS int
Group Volt/PF ctrl
Range [units] 0 .. 100 [%]
Related FW 3.0
Description This setpoint adjusts the relative integration factor (I-factor) of the VAr-sharing PI
loop. The gain factor (P-factor) for the VAr-sharing loop is adjusted by the setpoint
VS
Setpoint: TauVoltActuat
Group Volt/PF ctrl
Range [units] 1.0 .. 300.0 [s]
Related FW 3.0
Description This setpoint is used to adjust the trasformation ratio of the AVRi output to the
pulses at the binary outputs
duration which is needed for the AVR to change the requested voltage from
minimum to maximum.
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
:
:
Regulation loops overview
gain.
for general information about
AVR up and AVR dn. Adjust the setpoint to the pulse
VS
170
