ComAp IG-NT Reference Manual page 123

setpoint
Setpoint: CoolDnAfterBOC
Group Engine Params
Range [units] STOP, INFIN COOLING [-]
Related FW 3.0
Force value YES
possible
Description The setpoint selects the controller behavior in cooling phase after a BOC alarm:
STOP
INFIN COOLING
Setpoint: Cooldown optim
Group Engine params
Range [units] DISABLED, ENABLED [-]
Related FW 3.0
Description This setpoint enables optimalization of the cooling phase length based on the
previous gen-set load.
DISABLED
ENABLED
Setpoint: AfterCool time
Group Engine params
Range [units] 0 .. 3600 [s]
Related FW 3.0
Force value YES
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
Cooldown optim.
The controller behaves as usually, e.g. the cooling phase
lasts for period adjusted by the setpoint
then the gen-set is stopped.
The cooling phase is not finished automatically when the
Cooling time
until another event changes the it's state, e.g. it is
manually stopped. If the gen-set is in AUT mode and the
alarm is not active and has been reset the gen-set
returns to loaded state automatically.
The length of the cooling phase is given by the setpoint
Cooling time regardless of the previous gen-set load.
The length of the cooling phase is linearly reduced according
to the gen-set load in the moment the stop sequence started
(i.e. prior to the gen-set begun to ramp down or opened the
GCB). If the load was 100% of the
will be 100% of the setpoint
the length will be reduced to 50% etc...
elapses. The gen-set remains in cooling
nominal power
Cooling time, if the load was 50%
Cooling time and
the length
