Value: Gen V unbal
Group Gener values
Units %
Related FW 3.0
Description Generator voltage unbalance. The value is calculated as maximal difference of
two phase voltages at one moment and expressed in % of the nominal voltage.
N
OTE
This value can be used for creating the generator voltage unbalance protection
using the "universal analog protections".
Value: Gen I unbal
Group Gener values
Units V
Related FW 3.0
Description Generator current unbalance. The value is calculated as maximal difference of
two phase currents at one moment and expressed in % of the nominal current.
N
OTE
This value can be used for creating the generator current unbalance protection
using the "universal analog protections".
Value: Slip freq
Group Gener values
Units Hz
Related FW 3.0
Description Differential frequency between the generator and the mains/bus.
Value: Angle
Group Gener values
°
Units
Related FW 3.0
Description The angle between the phasors of the generator and mains/bus voltage.
Group: Bus values
Value: Mains freq
Group Mains values
Units Hz
Related FW 3.0
Description Mains frequency. The frequency is measured in the phase L3.
