Basic settings:
VoltProtSelect = PHASE-PHASE
Gener protect: Gen >V BOC
Gen <V BOC
Gen >V Sd
Gen V del
Gen >f
Gen <f
Gen f del
Generator voltage and frequency protections - limits and indications
Basic settings:
VoltProtSelect = PHASE-NEUTRAL
Gener protect: Gen >V BOC
Gen <V BOC
Gen V Sd
Gen V del
Gen >f
Gen <f
Gen f del
Basic settings:
VoltProtSelect = PHASE-PHASE
Gener protect: Gen >V BOC
Gen <V BOC
Gen V Sd
Gen V del
Gen >f
Gen <f
Gen f del
Shutdown override
If the Binary input shutdown override (Sd override) is closed, all 2
engine run in an emergency situation, e.g. sprinkler devices power supply.
All protections are shown in Alarmlist and recorded into History, but the controller doesn't stop the engine
because of them. If the input is deactivated and some protections are still active or not yet reset, the
controller starts to take these protections into account and consequently stops the engine.
H
INT
nd
All 2 level protections are locked out, except of these:
- Emergency stop
- Overspeed
- Underspeed (only if Fuel solenoid = GAS ENGINE)
- Binary and analog protections configured as Sd override type. In fact this protection type means
"Unoverridable shutdown", i.e. it works the same way as standard shutdown protection, however it can not
be overriden (blocked) by the Sd override input.
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
Bus V L1-L2
Bus V L2-L3
Bus V L3-L1
Bus freq
BOC L1 under
Gen V L1-N
BOC L2 under
Gen V L2-N
BOC L3 under
Gen V L3-N
BOC L1 over
BOC fg under
BOC L2 over
BOC fg over
BOC L3 over
Gen freq
BOC L12 under
Gen V L1-L2
BOC L23 under
Gen V L2-L3
BOC L31 under
Gen V L3-L1
BOC L12 over
BOC fg under
BOC L23 over
BOC fg over
BOC L31 over
Gen freq
