ComAp IG-NT Reference Manual page 85

Setpoint: #SysLdCtrl PtM
Group Process Control
Range [units] BASELOAD, LDSHARING [-]
Related FW 3.0
Description This setpoint is used to adjust the power control mode in parallel-to-mains
operation.
Setpoint: #SysPFCtrl PtM
Group Process Control
Range [units] BASEPF, VSHARING [-]
Related FW 3.0
Description This setpoint is used to adjust the power factor control mode in parallel-to-mains
operation.
N
OTE
If the power factor control mode is switched to VSHARING the
must be switched to LDSHARING.
Setpoint: SysBaseLdMode
Group Process control
Range [units] INTERNAL, EXTERNAL [-]
Related FW 3.0
Force value YES
possible
Description This setpoint selects from where the System Base load value is taken if the load
control mode in parallel-to-mains operation is switched to baseload (i.e.
#SysLdCtrl PtM
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
BASELOAD: The gen-set is controlled by the load control loop (i.e. as in
SPtM) to provide constant proportional part of the requested system
baseload (see SysBaseLdMode). The proportional parts of all running
gen-sets are equal relative to their nominal power.
LDSHARING: The gen-set load controlled by the load sharing loop as in
island operation. This option is intended only for systems with InteliMains,
where the InteliMains controls the power of the group via the load sharing
line (e.g. in Import/Export mode).
BASEPF: The gen-set power factor is controlled to a preadjusted level
#SysPwrFactor.
VSHARING: The power factor is equalized with other gen-sets according
to the actual reactive load.
:
= BASELOAD).
load control mode
