The output is closed while the controller is currently in SEM mode. This output is
available in IS-NT controllers only.
Binary output: MODES: Aut mode
Related FW 3.0
Description The output is closed while the controller is currently in AUT mode (either switched
by the mode selector on the front panel or by the input
Binary output: MODES: Test mode
Related FW 3.0
Description The output is closed while the controller is currently in TEST mode (either
switched by the mode selector on the front panel or by the input
Binary output: SystReady
Related FW 3.0
Description The output is closed while the group of gen-sets has enough capacity to fulfil the
requested power
enough capacity to fulfil the reserve even if all the gen-sets will run.
N
OTE
Fulfiled reserve means the actual reserve is above the requested reserve for start.
N
OTE
This output do not indicate the requested reserve has been already fulfiled. It
only indicates whether the system is able to fulfil it or not.
Binary output: Ready for Load
Related FW 3.0
Description This output is closed while the gen-set is running, it's voltage and frequency are in
limits and the GCB is able to be closed or is already closed.
Binary output: Gen-set active
Related FW 3.0
Description The output closes at the beginning of the prestart phase and opens after the gen-
set has been fully stopped. If the gen-set fails to start the output opens after the
last cranking attempt.
N
OTE
The output also closes if the engine begins to rotate spontaneously.
Binary output: Operational
Related FW 3.0
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
reserve. If this output is not closed it means the system has not
:
:
:
Remote AUT).
Remote TEST).
