How to Programme
2.1.7 Main Menu Mode
2 2 Select the Main Menu mode by pressing the [Main Menu]
key. Illustration 6.2 shows the resulting read-out, which
appears on the display of the GLCP.
Lines 2 through 5 on the display show a list of parameter
groups which can be chosen by toggling the up and down
buttons.
Illustration 2.27 Display example.
Each parameter has a name and number which remain the
same regardless of the programming mode. In the Main
Menu mode, the parameters are divided into groups. The
first digit of the parameter number (from the left) indicates
the parameter group number.
All parameters can be changed in the Main Menu. The
configuration of the unit (1-00 Configuration Mode) will
determine other parameters available for programming.
For example, selecting Closed Loop enables additional
parameters related to closed loop operation. Option cards
added to the unit enable additional parameters associated
with the option device.
2.1.8 Parameter Selection
In the Main Menu mode, the parameters are divided into
groups. Select a parameter group by means of the
navigation keys.
The following parameter groups are accessible:
Group no.
0-**
1-**
2-**
3-**
4-**
5-**
6-**
8-**
11-**
13-**
14-**
15-**
16-**
18-**
20-**
22
VLT
1107 RPM 3.84 A
Main menu
0 - ** Operation/Display
1 - ** Load/Motor
2 - ** Brakes
3 - ** Reference / Ramps
Parameter group
Operation/Display
Load/Motor
Brakes
References/Ramps
Limits/Warnings
Digital In/Out
Analog In/Out
Comm. and Options
LonWorks
Smart Logic
Special Functions
Drive Information
Data Readouts
Info & Readouts
Drive Closed Loop
MG16H102 - VLT
®
Refrigeration Drive Programming Guide
Group no.
21-**
22-**
23-**
25-**
26-**
28-**
Table 2.6 Parameter groups.
1 (1)
After selecting a parameter group, choose a parameter by
means of the navigation keys.
The middle section on the GLCP display shows the
parameter number and name as well as the selected
parameter value.
Illustration 2.28 Display example.

2.1.9 Changing Data

The procedure for changing data is the same in the Quick
menu and the Main menu mode. Press [OK] to change the
selected parameter.
The procedure for changing data depends on whether the
selected parameter represents a numerical data value or a
text value.

2.1.10 Changing a Text Value

If the selected parameter is a text value, change the text
value with the [
Place the cursor on the value to save and press [OK].
Illustration 2.29
®
is a registered Danfoss trademark
Parameter group
Ext. Closed Loop
Application Functions
Time-based Functions
Pack Controller
Analog I/O Option
Compressor Functions
740RPM 10.64A
Basic Settings
0 -01 Language
[0] English
▲ ▼
] [ ] keys.
740RPM 10.64 A
Basic Settings
0 -01 Language
[0] English
1 [1]
0-0 *
1 [1]
0-0 *
