Parameter Description
5-63 Terminal 29 Pulse Output Variable
Select the variable for viewing on the terminal 29 display. Same
options and functions as parameter group 5-6*.
Option:
[100]
3 3
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[108]
[109]
[113]
[114]
[115]
5-65 Pulse Output Max Freq #29
Set the maximum frequency for terminal 29 corresponding to the
output variable set in 5-63 Terminal 29 Pulse Output Variable.
Range:
5000 Hz
*
5-66 Terminal X30/6 Pulse Output Variable
Select the variable for read-out on terminal X30/6.
This parameter is active when option module MCB 101 is
installed in the frequency converter.
Same options and functions as parameter group 5-6*.
Option:
[0]
*
[45]
[48]
[100]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[108]
[109]
[113]
[114]
[115]
NOTE
This parameter cannot be adjusted while the motor is
running.
70
VLT
Function:
Output frequency
Reference
Feedback
Motor Current
Torque rel to limit
Torq relate to rated
Power
Speed
Torque
Max Out Freq
Ext. Closed Loop 1
Ext. Closed Loop 2
Ext. Closed Loop 3
Function:
[0 - 32000 Hz]
Function:
No operation
Bus ctrl.
Bus ctrl., timeout
Output frequency
Reference
Feedback
Motor Current
Torque rel to limit
Torq relate to rated
Power
Speed
Torque
Max Out Freq
Ext. Closed Loop 1
Ext. Closed Loop 2
Ext. Closed Loop 3
MG16H102 - VLT
®
Refrigeration Drive Programming Guide
5-68 Pulse Output Max Freq #X30/6
Select the maximum frequency on terminal X30/6 referring to
the output variable in 5-66 Terminal X30/6 Pulse Output Variable.
This parameter is active when option module MCB 101 is
mounted in the frequency converter.
Range:
5000 Hz
*
3.7.7 5-9* Bus Controlled
This parameter group selects digital and relay outputs via
a fieldbus setting.
5-90 Digital & Relay Bus Control
Range:
0 [0 -
*
2147483647 ]
5-93 Pulse Out #27 Bus Control
Range:
0 % [0 - 100 %] Contains the frequency to apply to the
*
®
is a registered Danfoss trademark
Function:
[0 - 32000 Hz]
Function:
This meter holds the state of the digital
outputs and relays that is controlled by
bus.
A logical '1' indicates that the output is
high or active.
A logical '0' indicates that the output is low
or inactive.
Bit 0 CC Digital Output Terminal 27
Bit 1 CC Digital Output Terminal 29
Bit 2 GPIO Digital Output Terminal X
30/6
Bit 3 GPIO Digital Output Terminal X
30/7
Bit 4 CC Relay 1 output terminal
Bit 5 CC Relay 2 output terminal
Bit 6 Option B Relay 1 output terminal
Bit 7 Option B Relay 2 output terminal
Bit 8 Option B Relay 3 output terminal
Bit 9-15 Reserved for future terminals
Bit 16 Option C Relay 1 output terminal
Bit 17 Option C Relay 2 output terminal
Bit 18 Option C Relay 3 output terminal
Bit 19 Option C Relay 4 output terminal
Bit 20 Option C Relay 5 output terminal
Bit 21 Option C Relay 6 output terminal
Bit 22 Option C Relay 7 output terminal
Bit 23 Option C Relay 8 output terminal
Bit Reserved for future terminals
24-31
Table 3.14
Function:
digital output terminal 27, when it is
configured as [Bus Controlled].
