Parameter Description
8-05 End-of-Timeout Function
Option: Function:
[0] Hold set-up Retains the set-up selected in 8-04 Control
Timeout Function and displays a warning, until
8-06 Reset Control Timeout toggles. Then the
frequency converter resumes its original set-
up.
[1] Resume set- Resumes the set-up active before the time-
*
up out.
8-06 Reset Control Timeout
Option: Function:
This parameter is active only when the choice [0]
Hold set-up has been selected in 8-05 End-of-
Timeout Function.
[0] Do not Retains the set-up specified in 8-04 Control
*
reset Timeout Function, [7] Set-up 1, [8] Set-up 2, [9] Set-
up 3 and [10] Set-up 4 following a control time-
out.
[1] Do Returns the frequency converter to the original
reset set-up following a control word time-out. When
the value is set to [1] Do reset, the frequency
converter performs the reset and then
immediately reverts to the [0] Do not reset setting.
8-07 Diagnosis Trigger
Option: Function:
This parameter has no function for
BACnet.
[0] Disable
*
[1] Trigger on alarms
[2] Trigger alarm/warn.
3.9.3 8-1* Ctrl. Word Settings
8-10 Control Profile
Option: Function:
Select the interpretation of the control
and status words corresponding to the
installed fieldbus. Only the selections
valid for the fieldbus installed in slot A
will be visible in the LPC display.
[0] FC profile
*
[1] PROFIdrive profile
[5] ODVA
[7] CANopen DSP 402
8-13 Configurable Status Word STW
Option: Function:
This parameter enables configuration of bits
12–15 in the status word.
[0] No function
®
VLT Refrigeration Drive Programming Guide
8-13 Configurable Status Word STW
Option:
[1]
[2]
[3]
[10] T18 DI
[11] T19 DI
[12] T27 DI
[13] T29 DI
[14] T32 DI
[15] T33 DI
[16] T37 DI
[21] Thermal
[30] Brake fault
[40] Out of ref.
[60] Comtor 0
[61] Comtor 1
[62] Comtor 2
[63] Comtor 3
[64] Comtor 4
®
MG16H102 - VLT is a registered Danfoss trademark
Function:
Profile Function corresponds to the profile default
*
Default selected in 8-10 Control Profile.
Alarm 68 Only set in case of an Alarm 68.
Only
Trip excl. Set in case of a trip, except if Alarm 68
Alarm 68 executes the trip.
The bit indicates the status of terminal 18.
status. "0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 19.
status. "0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 27.
status. "0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 29.
status. "0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 32.
status. "0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 33.
status. "0" indicates that the terminal is low
"1" indicates that the terminal is high
The bit indicates the status of terminal 37.
status 0" indicates T37 is low (safe stop)
"1" indicates T37 is high (normal)
The thermal warning turns on when the
warning temperature exceeds the limit in the motor,
the frequency converter, the brake resistor,
or the thermistor.
Output is Logic '1' when the brake IGBT is
(IGBT) short-circuited. Use this function to protect
the frequency converter if there is a fault on
the brake modules. Use the output/relay to
cut out the main voltage from the frequency
converter.
range
See parameter group 13-1*. If Comtor 0 is
evaluated as TRUE, the output goes high.
Otherwise, it is low.
See parameter group 13-1*. If Comtor 1 is
evaluated as TRUE, the output goes high.
Otherwise, it is low.
See parameter group 13-1*. If Comtor 2 is
evaluated as TRUE, the output goes high.
Otherwise, it is low.
See parameter group 13-1*. If Comtor 3 is
evaluated as TRUE, the output goes high.
Otherwise, it is low.
See parameter group 13-1*. If Comtor 4 is
evaluated as TRUE, the output goes high.
Otherwise, it is low.
