Parameter Lists
Par. No. # Parameter description
21-44 Ext. 2 Dif. Gain Limit
21-5* Ext. CL 3 Ref./Fb.
21-50 Ext. 3 Ref./Feedback Unit
21-51 Ext. 3 Minimum Reference
21-52 Ext. 3 Maximum Reference
21-53 Ext. 3 Reference Source
21-54 Ext. 3 Feedback Source
21-55 Ext. 3 Setpoint
21-57 Ext. 3 Reference [Unit]
21-58 Ext. 3 Feedback [Unit]
21-59 Ext. 3 Output [%]
21-6* Ext. CL 3 PID
21-60 Ext. 3 Normal/Inverse Control
21-61 Ext. 3 Proportional Gain
21-62 Ext. 3 Integral Time
21-63 Ext. 3 Differentation Time
21-64 Ext. 3 Dif. Gain Limit
Table 4.18

4.1.18 22-** Application Functions

Par. No. # Parameter description
22-0* Miscellaneous
22-00 External Interlock Delay
22-2* No-Flow Detection
22-20 Low Power Auto Set-up
22-21 Low Power Detection
22-22 Low Speed Detection
22-23 No-Flow Function
22-24 No-Flow Delay
22-26 Dry Pump Function
22-27 Dry Pump Delay
22-3* No-Flow Power Tuning
22-30 No-Flow Power
22-31 Power Correction Factor
22-32 Low Speed [RPM]
22-33 Low Speed [Hz]
22-34 Low Speed Power [kW]
22-35 Low Speed Power [HP]
22-36 High Speed [RPM]
22-37 High Speed [Hz]
22-38 High Speed Power [kW]
22-39 High Speed Power [HP]
22-4* Sleep Mode
22-40 Minimum Run Time
22-41 Minimum Sleep Time
22-42 Wake-up Speed [RPM]
22-43 Wake-up Speed [Hz]
®
VLT Refrigeration Drive Programming Guide
Default value 4-set-up
5 N/A All set-ups
[1] % All set-ups
0 ExtPID3Unit All set-ups
100 ExtPID3Unit All set-ups
[0] No function All set-ups
[0] No function All set-ups
0 ExtPID3Unit All set-ups
0 ExtPID3Unit All set-ups
0 ExtPID3Unit All set-ups
0 % All set-ups
[0] Normal All set-ups
0.01 N/A All set-ups
10000 s All set-ups
0 s All set-ups
5 N/A All set-ups
Default value
0 s All set-ups
[0] Off All set-ups
[0] Disabled All set-ups
[0] Disabled All set-ups
[0] Off All set-ups
10 s All set-ups
[0] Off All set-ups
10 s All set-ups
0 kW All set-ups
100 % All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
10 s All set-ups
10 s All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
®
MG16H102 - VLT is a registered Danfoss trademark
Change Conver-
during sion index
operation
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
4-set-up Change Conver-
during sion index
operation
TRUE
FALSE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
TRUE
Type
-1 Uint16
- Uint8
-3 Int32
-3 Int32
- Uint8
- Uint8
-3 Int32
-3 Int32
-3 Int32
0 Int32
- Uint8
-2 Uint16
-2 Uint32
-2 Uint16
-1 Uint16
Type
0 Uint16
- Uint8
- Uint8
- Uint8
- Uint8
0 Uint16
- Uint8
0 Uint16
1 Uint32
0 Uint16
67 Uint16
-1 Uint16
1 Uint32
-2 Uint32
67 Uint16
-1 Uint16
1 Uint32
-2 Uint32
0 Uint16
0 Uint16
67 Uint16
-1 Uint16
183
4 4
