Parameter Description
6-40 Terminal X30/12 Low Voltage
Range: Function:
0.07 V [ 0 - par. 6-41 Sets the analog input scaling value to
*
V] correspond to the low reference/
feedback value set in 6-44 Term. X30/12
Low Ref./Feedb. Value.
6-41 Terminal X30/12 High Voltage
Range: Function:
10 V [ par. 6-40 - 10 Sets the analog input scaling value to
*
V] correspond to the high reference/
feedback value set in 6-45 Term. X30/12
High Ref./Feedb. Value.
6-44 Term. X30/12 Low Ref./Feedb. Value
Range: Function:
0 [-999999.999 - Sets the analog output scaling value
*
999999.999 ] to correspond to the low voltage
value set in 6-40 Terminal X30/12
Low Voltage.
6-45 Term. X30/12 High Ref./Feedb. Value
Range: Function:
100 [-999999.999 - Sets the analog input scaling value
*
999999.999 ] to correspond to the high voltage
value set in 6-41 Terminal X30/12
High Voltage.
6-46 Term. X30/12 Filter Time Constant
Range: Function:
0.001 s [0.001 - 10 s] A 1 st
* order digital low pass filter time
constant for suppressing electrical noise
on terminal X30/12.
NOTE
This parameter cannot be changed while the motor is
running.
6-47 Term. X30/12 Live Zero
Option: Function:
This parameter makes it possible to disable the
Live Zero monitoring. E.g. to be used if the
analog outputs are used as of a decentral I/O
system (e.g. when not of any frequency converter
related control functions, but feeding a Building
Management System with data)
[0] Disabled
*
[1] Enabled
3.8.7 6-5* Analog Output 1
Parameters for configuring the scaling and limits for
analog output 1, i.e. Terminal 42. Analog outputs are
current outputs: 0/4-20 mA. Common terminal (terminal
®
VLT Refrigeration Drive Programming Guide
39) is the same terminal and has the same electrical
potential for analog common and digital common
connection. Resolution on analog output is 12 bit.
6-50 Terminal 42 Output
Option:
[0]
[100]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[108]
[109]
[113]
[114]
[115]
[130]
[131]
[132]
[133]
[134]
[135]
[136]
[137]
[138]
[139]
[140]
®
MG16H102 - VLT is a registered Danfoss trademark
Function:
Select the function of Terminal 42
as an analog current output. A
motor current of 20 mA
corresponds to I
No operation
Output frequency 0-100 Hz, (0-20 mA)
Reference Minimum reference - Maximum
reference, (0-20 mA)
Feedback -200% to +200% of 20-14 Maximum
Reference/Feedb., (0-20 mA)
Motor Current 0 - Inverter Max. Current (16-37 Inv.
Max. Current), (0-20 mA)
Torque rel to limit 0 - Torque limit (4-16 Torque Limit
Motor Mode), (0-20 mA)
Torq relate to rated 0 - Motor rated torque, (0-20 mA)
Power 0 - Motor rated power, (0-20 mA)
Speed 0 - Speed High Limit (4-13 Motor
Speed High Limit [RPM] and
4-14 Motor Speed High Limit [Hz]),
(0-20 mA)
Torque
Max Out Freq
Ext. Closed Loop 1 0-100%, (0-20 mA)
Ext. Closed Loop 2 0-100%, (0-20 mA)
Ext. Closed Loop 3 0-100%, (0-20 mA)
Output freq. 0-100 Hz
4-20mA
Reference 4-20mA Minimum Reference - Maximum
Reference
Feedback 4-20mA -200% to +200% of 20-14 Maximum
Reference/Feedb.
Motor cur. 4-20mA 0 - Inverter Max. Current (16-37 Inv.
Max. Current)
Torq.% lim 4-20 mA 0 - Torque limit (4-16 Torque Limit
Motor Mode)
Torq.% nom 0 - Motor rated torque
4-20mA
Power 4-20mA 0 - Motor rated power
Speed 4-20mA 0 - Speed High Limit (4-13 and
*
4-14)
Torque 4-20mA
Bus ctrl. 0-100%, (0-20 mA)
Bus ctrl. 4-20 mA 0-100%
