How to Programme
7.
Highlighted area indicates digit selected for
change
2
2
8.
Press [Cancel] button to disregard change, or
press [OK] to accept change and enter the new
setting
Example of Changing Parameter Data
Assume 22-60 Broken Belt Function is set to [0 Off].
However, you want to monitor the fan-belt condition -
non- broken or broken - according to the folowing
procedure:
1.
Press Quick Menu key
2.
Choose Function Setups with the [
3.
Press [OK]
4.
Choose Application Settings with the [
5.
Press [OK]
6.
Press [OK] again for Fan Functions
7.
Choose Broken Belt Function by pressing [OK]
8.
With [
The frequency converter will now trip if a broken fan-belt
is detected.
Select [My Personal Menu] to display only the parameters,
which have been pre-selected and programmed as
personal parameters. For example, an AHU or pump OEM
may have pre-programmed these to be in My Personal
Menu during factory commissioning to make on-site
commissioning / fine tuning simpler. These parameters are
selected in 0-25 My Personal Menu. Up to 20 different
parameters can be programmed in this menu.
If [0 No Operation] is selected in 5-12 Terminal 27 Digital
Input, no connection to +24 V on terminal 27 is necessary
to enable start.
If [2 Coast Inverse] (factory default value) is selected in
5-12 Terminal 27 Digital Input, a connection to +24 V is
necessary to enable start.
Select [Changes Made] to get information about:
•
the last 10 changes. Use the up/down navigation
keys to scroll between the last 10 changed
parameters.
•
the changes made since factory setting.
Select [Loggings] to get information about the display line
read-outs. The information is shown as graphs.
Only display parameters selected in 0-20 Display Line 1.1
Small and 0-24 Display Line 3 Large can be viewed. It is
possible to store up to 120 samples in the memory for
later reference.
18
VLT
▼
▼
], choose [2] Trip
MG16H102 - VLT
®
Refrigeration Drive Programming Guide
Efficient Parameter Set-up for VLT Refrigeration Drive
Applications
The parameters can easily be set up for the vast majority
of the VLT Refrigeration Drive applications only by using
the [Quick Setup] option.
After pressing [Quick Menu], the different choices in the
Quick Menu are listed. See also illustration 6.1 below and
tables Q3-1 to Q3-4 in 2.1.6 Function Setups .
Example of using the Quick Setup option
Assume you want to set the Ramp Down Time to 100
seconds
1.
] key
2.
▼
] key
3.
4.
5.
6.
7.
8.
The new ramp-down time is now set to 100 seconds.
It is recommended to do the set-up in the order listed.
NOTE
A complete description of the function is found in the
parameter sections of these Operating Instructions.
18.1%
Quick menus
01 My personal menu
02 Quick setup
03 Function Setups
04 Wizard
Illustration 2.19 Quick Menu view.
The Quick Setup menu gives access to the 13 most
important setup parameters of the drive. After
programming the drive will, in most cases be ready for
operation. The 13* Quick Setup parameters are shown in
the table below. A complete description of the function is
given in the parameter description sections of this manual.
The display showing depends on choices made in
0-02 Motor Speed Unit and 0-03 Regional Settings. The
default settings of 0-02 Motor Speed Unit and 0-03 Regional
®
is a registered Danfoss trademark
Select [Quick Setup]. The first parameter
0-01 Language in Quick Setup appears
▼
Press [
] repeatedly until 3-42 Ramp 1 Ramp
Down Time appears with the default setting of 20
seconds
Press [OK]
◀
Press [
] to highlight the 3rd digit before the
comma
Change '0' to '1' by pressing [
▶
Press [
] to highlight the digit '2'
▼
Change '2' to '0' with the [
] button
Press [OK]
2.06A
▲
]
1(1)
