Parameter Description
4-16 Torque Limit Motor Mode
Range:
110 [
% 1000.0 %]
*
3 3
4-17 Torque Limit Generator Mode
Range:
100 [
% 1000.0 %]
*
4-18 Current Limit
Range:
Size [
related 1000.0 %]
*
4-19 Max Output Frequency
Range:
Size [
related 1000.0
*
Hz]
56
Function:
0 - Enter the maximum torque limit for motor
operation. The torque limit is active in the
speed range up to and including the rated
motor speed set in 1-25 Motor Nominal Speed.
To protect the motor from reaching the
stalling torque, the default setting is 1.1 x the
rated motor torque (calculated value). See
also 14-25 Trip Delay at Torque Limit for
further details.
If a setting in 1-00 Configuration Mode to
1-28 Motor Rotation Check is changed,
4-16 Torque Limit Motor Mode is not automat-
ically reset to the default setting.
Function:
0 - Enter the maximum torque limit for
generator mode operation. The torque limit
is active in the speed range up to and
including the rated motor speed (1-25 Motor
Nominal Speed). Refer to 14-25 Trip Delay at
Torque Limit for further details.
If a setting in 1-00 Configuration Mode to
1-28 Motor Rotation Check is changed,
4-17 Torque Limit Generator Mode is not
automatically reset to the default settings.
Function:
1.0 - Enter the current limit for motor and
generator operation. To protect the motor
from reaching the stalling torque, the
default setting is 1.1 x the rated motor
current (set in 1-24 Motor Current). If a
setting in 1-00 Configuration Mode to
1-28 Motor Rotation Check is changed,
4-16 Torque Limit Motor Mode to
4-18 Current Limit are not automatically
reset to the default settings.
Function:
1 - Enter the maximum output frequency
value. 4-19 Max Output Frequency specifies
the absolute limit on the frequency
converter output frequency for improved
safety in applications where accidental
over-speeding must be avoided. This
absolute limit applies to all configurations
and is independent of the setting in
1-00 Configuration Mode. This parameter
cannot be adjusted while the motor is
running.
MG16H102 - VLT
®
VLT Refrigeration Drive Programming Guide
4-19 Max Output Frequency
Range:
3.6.3 4-5* Adj. Warnings
Define adjustable warning limits for current, speed,
reference and feedback.
NOTE
Not visible in display, only in .
Warnings are shown on display, programmed output or
serial bus.
I
motor
I
LIM
(P 4-18)
I
HIGH
(P 4-51)
I
LOW
(P 4-50)
Illustration 3.20
4-50 Warning Current Low
Range:
0 A [ 0 - par.
*
4-51 A]
4-51 Warning Current High
Range:
Size
related
*
®
is a registered Danfoss trademark
Function:
When 1-10 Motor Construction is set to [1]
PM non salient SPM the maximum value is
limited to 300 Hz.
ON REF
IN RANGE
n n n
REF
MIN LOW HIGH
(P 4-11) (P 4-52) (P 4-53)
Function:
Enter the I value. When the motor current
LOW
falls below this limit (I
LOW
CURRENT LOW. The signal outputs can be
programmed to produce a status signal on
terminal 27 or 29 and on relay output 01 or
02. Refer to Illustration 3.20.
Function:
[ par. 4-50 Enter the I value. When the motor
HIGH
- par. current exceeds this limit (I
16-37 A]
display reads CURRENT HIGH. The signal
outputs can be programmed to
produce a status signal on terminal 27
or 29 and on relay output 01 or 02.
Refer to Illustration 3.20.
n
[RPM]
motor
n
MAX
(P 4-13)
), the display reads
), the
HIGH
