Danfoss VLT FC 103 Programming Manual page 21

How to Programme
2.1.6 Function Setups
2 2 The Function set-up provides quick and easy access to all
parameters required for the majority of VLT Refrigeration
Drive applications including most VAV and CAV supply and
return fans, cooling tower fans, Primary, Secondary and
Condenser Water Pumps and other pump, fan and
compressor applications.
How to access Function Set-up - example
How to change the output on "Analog output 42"
Status
28.8%
Auto Remote Running
Illustration 2.20 Step 1: Turn on the frequency converter (yellow
LED lights)
13.7%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
Illustration 2.21 Step 2: Press the [Quick Menus] key (Quick
Menus choices appear).
69.3%
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
Illustration 2.22 Step 3: Press
Setups. Press [OK].
28.4%
Function Setups
Q3-1 General Settings
Q3-2 Open Loop Settings
Q3-3 Closed Loop Settings
Q3-4 Application Settings
Illustration 2.23 Step 4: Function Setups choices appear. Choose
03-1 General Settings. Press [OK].
20
®
VLT Refrigeration Drive Programming Guide
1 (1)
2.63kW
5.66A
14.4Hz
0kWh
13.0A 1(1)
5.20A 1(1)
▲ ▼
/ to scroll down to Function
2.05A 1(1)
Q3
MG16H102 - VLT
26.0%
General Settings
Q3 - 10 Adv. Motor Settings
Q3 - 11 Analog Output
Q3 - 12 Clock Settings
Q3 - 13 Display Settings
Illustration 2.24 Step 5: Press
Analog Outputs. Press [OK].
26.3%
Analog Output
6 - 50 Terminal 42 Output
(100) Output frequency
Illustration 2.25 Step 6: Choose 6-50 Terminal 42 Output. Press
[OK].
43.4%
Analog Output
6-50 Terminal 42 Output
[107]
Illustration 2.26 Step 7: Press
different choices. Press [OK].
NOTE
For the quickest and easiest setup of the FC 103, please
use the FC 103 Wizard (see chapter Introduction)
®
is a registered Danfoss trademark
7.14A 1(1)
Q3-1
▲ ▼
/ to scroll down to i.e. Q3-11
5.82A 1(1)
03.11
1(1)
7.99A
Q3-11
Speed
▲ ▼
/ to select between the
