Parameter Description
5-13 Terminal 29 Digital Input
Option: Function:
Select the function from the available digital
input range and the additional options [60],
[61], [63] and [64]. Counters are used in
Smart Logic Control functions.
[0] No operation Functions are described under parameter
*
group 5-1*
5-14 Terminal 32 Digital Input
Option: Function:
Select the function from the available
digital input range and the additional
options [60], [61], [63] and [64]. Counters
are used in Smart Logic Control functions.
[39] Day/Night Functions are described under parameter
*
control group 5-1*
5-15 Terminal 33 Digital Input
Option: Function:
Select the function from the available digital
input range and the additional options [60],
[61], [63] and [64]. Counters are used in
Smart Logic Control functions.
[0] No operation Functions are described under parameter
*
group 5-1*
5-16 Terminal X30/2 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB101 is installed in the frequency
converter. Functions are described under
parameter group 5-1*
5-17 Terminal X30/3 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB101 is installed in the frequency
converter. Functions are described under
parameter group 5-1*
5-18 Terminal X30/4 Digital Input
Option: Function:
[0] No operation This parameter is active when option module
*
MCB101 is installed in the frequency
converter. Functions are described under
parameter group 5-1*
5-19 Terminal 37 Safe Stop
Option: Function:
[1] Safe Stop Coasts frequency converter when safe
*
Alarm stop is activated. Manual reset from LCP,
digital input or fieldbus.
[3] Safe Stop Coasts frequency converter when safe
Warning stop is activated (T-37 off). When safe
stop circuit is reestablished, the frequency
®
VLT Refrigeration Drive Programming Guide
5-19 Terminal 37 Safe Stop
Option:
Choises 4 - 9 are only available when the MCB 112 PTC
Thermistor Card is connected.
NOTE
When Auto Reset/Warning is selected the frequency
converter opens up for automatic restart.
Overview of functions, alarms and warnings
Function
No Function
Safe Stop Alarm
Safe Stop Warning
PTC 1 Alarm
PTC 1 Warning
PTC 1 & Relay A
PTC 1 & Relay W
PTC 1 & Relay A/W
PTC 1 & Relay W/A
Table 3.12
W means warning and A means alarm. For further information, see
Alarms and Warnings in section Troubleshooting in the Design Guide
or the Operating Instructions
A dangerous failure related to Safe Stop will give Alarm:
Dangerous Failure [A72].
Refer to Table 5.3 in .
3.7.3 5-3* Digital Outputs
Parameters for configuring the output functions for the
output terminals. The 2 solid-state digital outputs are
common for terminals 27 and 29. Set the I/O function for
terminal 27 in 5-01 Terminal 27 Mode, and set the I/O
function for terminal 29 in 5-02 Terminal 29 Mode. These
parameters cannot be adjusted while the motor is running.
[0]
[1]
®
MG16H102 - VLT is a registered Danfoss trademark
Function:
converter will continue without manual
reset.
No. PTC
[0] -
[1]* -
[3] -
[4] PTC 1 Safe Stop
[A71]
[5] PTC 1 Safe Stop
[W71]
[6] PTC 1 Safe Stop
[A71]
[7] PTC 1 Safe Stop
[W71]
[8] PTC 1 Safe Stop
[A71]
[9] PTC 1 Safe Stop
[W71]
The digital outputs can be programmed
with these functions:
No operation Default for all digital outputs and relay
outputs
Control ready The control board receives supply voltage.
3 3
Relay
-
Safe Stop [A68]
Safe Stop [W68]
-
-
Safe Stop [A68]
Safe Stop [W68]
Safe Stop [W68]
Safe Stop [A68]
63
