Parameter Description

3.4 Main Menu - Brakes - Group 2

3.4.1 2-0* DC-Brakes
Parameter group for configuring the DC brake and DC
hold functions.
3 3
2-00 DC Hold/Preheat Current
Range:
50 % [ 0 -
*
160 %]
NOTE
2-00 DC Hold/Preheat Current will not have effect when
1-10 Motor Construction = [1] PM, non salient SPM.
NOTE
The maximum value depends on the rated motor current.
Avoid 100 % current for too long. It may damage the
motor.
2-01 DC Brake Current
Range:
50 [ 0 -
% 1000 %]
*
NOTE
The maximum value depends on the rated motor current.
Avoid 100 % current for too long. It may damage the
motor.
2-02 DC Braking Time
Range:
10 s [0 - 60 s] Set the duration of the DC braking current set
*
2-03 DC Brake Cut In Speed [RPM]
Range:
Size related
*
RPM]
48
Function:
Enter a value for holding current as a
percentage of the rated motor current I
in 1-24 Motor Current. 100% DC holding current
corresponds to I .
M,N
This parameter holds the motor (holding
torque) or pre-heats the motor.
This parameter is active if [1] DC hold/Motor
Preheat is selected in 1-80 Function at Stop.
Function:
Enter a value for current as a percentage of the
rated motor current I , see 1-24 Motor Current.
M,N
100% DC braking current corresponds to I
DC brake current is applied on a stop
command, when the speed is lower than the
limit set in 2-03 DC Brake Cut In Speed [RPM];
when the DC Brake Inverse function is active; or
via the serial communication port. The braking
current is active during the time period set in
2-02 DC Braking Time.
Function:
in 2-01 DC Brake Current, once activated.
Function:
[ 0 - 0 Set the DC brake cut-in speed for
activation of the DC braking current
MG16H102 - VLT
®
VLT Refrigeration Drive Programming Guide
2-03 DC Brake Cut In Speed [RPM]
Range:
NOTE
2-03 DC Brake Cut In Speed [RPM] will not have effect when
set
M,N
1-10 Motor Construction = [1] PM, non salient SPM.
2-04 DC Brake Cut In Speed [Hz]
Range:
Size related
2-06 Parking Current
Range:
50 %
*
%]
NOTE
2-06 Parking Current and 2-07 Parking Time: Only active if
PM motor construction is selected in 1-10 Motor
Construction.
2-07 Parking Time
. Range:
M,N
3 s [0.1 - 60 s] Set the duration of the ing current time set in
*
3.4.2 2-1* Brake Energy Funct.
Parameter group for selecting dynamic braking parameters.
Only valid for frequency converters with brake chopper.
2-10 Brake Function
Option: Function:
[0] Off No brake resistor installed.
*
®
is a registered Danfoss trademark
Function:
set in 2-01 DC Brake Current, upon a
stop command.
When 1-10 Motor Construction is set to
[1] PM non salient SPM this value is
limited to 0 rpm (OFF)
[ 0 - 0.0 Hz]
*
Function:
[ 0 - 1000 Set current as percentage of rated motor
current, 1-24 Motor Current. Active in
connection with 1-73 Flying Start. The ing
current is active during the time period set
in 2-07 Parking Time.
Function:
2-06 Parking Current. Active in connection with
1-73 Flying Start.
Available selections depend on 1-10 Motor Construction:
[0] Asynchron:
[0] off
[1] Resistor brake
[2] AS brake
[1] PM non salient:
[0] off
[1] Resistor brake
Function:
