0-20 Display Line 1.1 Small
Option: Function:
[1007] Readout Bus Off View the number of Bus Off events
Counter since the last power-up.
[1013] Warning Parameter View a DeviceNet-specific warning
word. One sete bit is assigned to
every warning.
[1501] Running Hours View the number of running hours
of the motor.
[1502] kWh Counter View the mains power consumption
in kWh.
[1600] Control Word View the Control Word sent from
the frequency converter via the
serial communication port in hex
code.
[1601] Reference [Unit] Total reference (sum of digital/
analog/preset/bus/freeze ref./catch
up and slow-down) in selected unit.
[1602] Reference [%] Total reference (sum of digital/
analog/preset/bus/freeze ref./catch
up and slow-down) in percent.
[1603] Status Word Present status word
[1605] Main Actual Value View the two-byte word sent with
[%] the Status word to the bus Master
reporting the Main Actual Value.
[1609] Custom Readout View the user-defined readouts as
defined in 0-30 Custom Readout
Unit, 0-31 Custom Readout Min Value
and 0-32 Custom Readout Max
Value.
[1610] Power [kW] Actual power consumed by the
motor in kW.
[1611] Power [hp] Actual power consumed by the
motor in HP.
[1612] Motor Voltage Voltage supplied to the motor.
[1613] Frequency Motor frequency, i.e. the output
frequency from the frequency
converter in Hz.
[1614] Motor current Phase current of the motor
measured as effective value.
[1615] Frequency [%] Motor frequency, i.e. the output
frequency from the frequency
converter in percent.
[1616] Torque [Nm] Present motor load as a percentage
of the rated motor torque.
[1617] Speed [RPM] Motor speed reference. Actual
speed will depend on slip compen-
sation being used (compensation
set in 1-62 Slip Compensation). If not
used, actual speed will be the value
®
VLT Refrigeration Drive Programming Guide
0-20 Display Line 1.1 Small
Option:
[1618] Motor Thermal
[1622] Torque [%]
[1630] DC Link Voltage
[1632] Brake Energy /s
[1633] Brake Energy /2 min Brake power transferred to an
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1636] Inv. Nom. Current
[1637] Inv. Max. Current
[1638] SL Controller State
[1639] Control Card Temp.
[1650] External Reference
[1652] Feedback[Unit]
[1653] Digi Pot Reference
[1654] Feedback 1 [Unit]
[1655] Feedback 2 [Unit]
[1656] Feedback 3 [Unit]
[1660] Digital Input
®
MG16H102 - VLT is a registered Danfoss trademark
Function:
read in the display minus motor
slip.
Thermal load on the motor,
calculated by the ETR function. See
also parameter group 1-9* Motor
Temperature.
Shows the actual torque produced,
in percentage.
Intermediate circuit voltage in the
frequency converter.
Present brake power transferred to
an external brake resistor.
Stated as an instantaneous value.
external brake resistor. The mean
power is calculated continuously for
the most recent 120 seconds.
Present heat sink temperature of
the frequency converter. The cut-
out limit is 95 ± 5° C; cutting back
in occurs at 70 ± 5° C.
Percentage load of the inverters
Nominal current of the frequency
converter
Maximum current of the frequency
converter
State of the event executed by the
control
Temperature of the control card.
Sum of the external reference as a
percentage, i.e. the sum of analog/
pulse/bus.
Reference value from programmed
digital input(s).
View the contribution of the digital
potentiometer to the actual
reference Feedback.
View the value of Feedback 1. See
also 20-0*.
View the value of Feedback 2. See
also 20-0*.
View the value of Feedback 3. See
also parameter group 20-0*.
Displays the status of the digital
inputs. Signal low = 0; Signal high
= 1.
Regarding order, see 16-60 Digital
Input. Bit 0 is at the extreme right.
