Parameter Description
18-12 Fire Mode Log: Date and Time
Range: Function:
Size [ 0 - This parameter contains an array with 10
related 0 ] elements. The parameter shows at which
*
date and time the logged event occurred.
The function relies on that the actual date
and time has been set in 0-70 Set Date and
Time. Note: There is no build in battery
back up of the clock. An external back up
must be used, eg the one in the MCB 109
Analog I/O option card. See Clock Settings,
parameter group 0-7*.
3.14.3 18-3* Analog I/O
Parameters for reporting the digital and analog I/O ports.
18-30 Analog Input X42/1
Range: Function:
0 [-20 - Read out of the value of the signal applied to
*
20 ] terminal X42/1 on the Analog I/O Card.
The units of the value shown in the LCP will
correspond to the mode selected in
26-00 Terminal X42/1 Mode.
18-31 Analog Input X42/3
Range: Function:
0 [-20 - Read out of the value of the signal applied to
*
20 ] terminal X42/3 on the Analog I/O Card.
The units of the value shown in the LCP will
correspond to the mode selected in
26-01 Terminal X42/3 Mode.
18-32 Analog Input X42/5
Range: Function:
0 [-20 - Read out of the value of the signal applied to
*
20 ] terminal X42/5 on the Analog I/O Card.
The units of the value shown in the LCP will
correspond to the mode selected in
26-02 Terminal X42/5 Mode.
18-33 Analog Out X42/7 [V]
Range: Function:
0 [0 - 30 ] Read out of the value of the signal applied to
*
terminal X42/7 on the Analog I/O Card.
The value shown reflects the selection in
26-40 Terminal X42/7 Output.
18-34 Analog Out X42/9 [V]
Range: Function:
0 [0 - 30 ] Read out of the value of the signal applied to
*
terminal X42/9 on the Analog I/O Card.
The value shown reflects the selection in
26-50 Terminal X42/9 Output.
®
VLT Refrigeration Drive Programming Guide
18-35 Analog Out X42/11 [V]
Range:
0
®
MG16H102 - VLT is a registered Danfoss trademark
Function:
[0 - 30 ] Read out of the value of the signal applied to
*
terminal X42/11 on the Analog I/O Card.
The value shown reflects the selection in
26-60 Terminal X42/11 Output.
