Parameter Description
6-23 Terminal 54 High Current
Range:
20 mA [
*
20 mA]
3 3
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
-1 [-999999.999 -
*
999999.999 ]
6-25 Terminal 54 High Ref./Feedb. Value
Range:
Size related
*
999999.999 ]
6-26 Terminal 54 Filter Time Constant
Range:
0.001 s [0.001 - 10
*
s]
NOTE
This parameter cannot be adjusted while the motor is
running.
6-27 Terminal 54 Live Zero
Option:
[0] Disabled
[1] Enabled
*
3.8.5 6-3* Analog Input 3 MCB 101
Parameter group for configuring the scale and limits for
analog input 3 (X30/11) placed on option module MCB
101.
74
Function:
par. 6-22 - Enter the high current value
corresponding to the high reference/
feedback value set in 6-25 Terminal 54
High Ref./Feedb. Value.
Function:
Enter the analog input scaling value
that corresponds to the low
voltage/low current value set in
6-20 Terminal 54 Low Voltage and
6-22 Terminal 54 Low Current.
Function:
[-999999.999 - Enter the analog input scaling
value that corresponds to the
high voltage/high current value
set in 6-21 Terminal 54 High
Voltage and 6-23 Terminal 54
High Current.
Function:
Enter the time constant. This is a first-
order digital low pass filter time constant
for suppressing electrical noise in
terminal 54. A high time constant value
improves dampening but also increases
the time delay through the filter.
Function:
This parameter makes it possible to disable the
Live Zero monitoring. E.g. to be used if the
analog outputs are used as of a de-central I/O
system (e.g. when not as of any frequency
converter related control functions, but feeding a
Building Management System with data).
MG16H102 - VLT
®
VLT Refrigeration Drive Programming Guide
6-30 Terminal X30/11 Low Voltage
Range:
0.07 V
*
6-31 Terminal X30/11 High Voltage
Range:
10 V
*
V]
6-34 Term. X30/11 Low Ref./Feedb. Value
Range:
0 [-999999.999 -
*
999999.999 ]
6-35 Term. X30/11 High Ref./Feedb. Value
Range:
100
*
999999.999 ]
6-36 Term. X30/11 Filter Time Constant
Range:
0.001 s
*
NOTE
This parameter cannot be changed while the motor is
running.
6-37 Term. X30/11 Live Zero
Option:
[0] Disabled
*
[1] Enabled
*
3.8.6 6-4* Analog Input 4 MCB 101
Parameter group for configuring the scale and limits for
analog input 4 (X30/12) placed on option module MCB
101.
®
is a registered Danfoss trademark
Function:
[ 0 - par. 6-31 Sets the analog input scaling value to
V] correspond to the low reference/
feedback value (set in 6-34 Term.
X30/11 Low Ref./Feedb. Value).
Function:
[ par. 6-30 - 10 Sets the analog input scaling value to
correspond to the high reference/
feedback value (set in 6-35 Term. X30/11
High Ref./Feedb. Value).
Function:
Sets the analog input scaling value
to correspond to the low voltage
value (set in 6-30 Terminal X30/11
Low Voltage).
Function:
[-999999.999 - Sets the analog input scaling value
to correspond to the high voltage
value (set in 6-31 Terminal X30/11
High Voltage).
Function:
[0.001 - 10 s] A 1 st
order digital low pass filter time
constant for suppressing electrical noise
on terminal X30/11.
Function:
This parameter makes it possible to disable the
Live Zero monitoring. E.g. to be used if the
analog outputs are used as of a decentral I/O
system (e.g. when not of any frequency converter
related control functions, but feeding a Building
Management System with data).
