1. General Presentation

The terms "Gripper", "EPick Gripper", "EPick Vacuum Gripper" and "EPick" used in the following manual all refer to the Robotiq
EPick Vacuum Gripper. The Robotiq EPick Vacuum Gripper is a robotic peripheral designed for industrial applications. The
vacuum is generated with an electric vacuum pump. Its design makes it a unique robotic end-of-arm tool to quickly pick, place and
handle a large range of parts of varying sizes and shapes.
Info
The following section presents the key features of the Gripper and must not be considered as appropriate to the
operation of the Gripper. Each feature is detailed in the appropriate section.
Info
The following manual uses the metric system. Unless specified, all dimensions are in millimeters.
1.1. Gripper nomenclature
1.1.1. EPick Gripper
The EPick Gripper is a vacuum Gripper that generates a vacuum with an electric vacuum pump.. It is equipped with one or multiple
suction cups. Each suction cup can be adapted to your application and grasping needs. The EPick Gripper is compatible with the
Robotiq standard coupling interface.
Fig. 1-1: Robotiq EPick Gripper
