3
Press the [ENTER] key.

Automatic Checking of the Media Thickness

Media thickness is automatically checked by the gap pin located at the center of the carriage.
1
Set the media.
• Be sure to set the media within the print range. If automatic thickness check is conducted without
inserting the media, the print heads may get damaged.
2
Press the [FUNCTION] key in LOCAL.
3
Press
4
Press the [ENTER] key.
5
Press
6
Press the [ENTER] key.
• To prepare the machine for the thickness check, the Y-bar is raised to the highest point.
• The carriage moves inside the print area.
7
Press the [ENTER] key.
• The media thickness is checked automatically.
• The checked thickness is displayed.
• The carriage returns to the retracted position, and the display returns to Step 5.
THICKNESS CHECK
** CHECKING **
8
Press the [END] key several times to end the operation.
• Tolerance of the automatic thickness check is ±0.1 mm.
ORIGIN SETUP
HEAD GAP = 1.2
FUNCTION
VIEW
to select the [HEAD HEIGHT].
FUNCTION
HEAD HEIGHT
HEAD HEIGHT
MEDIA THICKNESS
to select the [THICKNESS CHECK].
HEAD HEIGHT
THICKNESS CHECK
** MOVING NOW **
PLEASE WAIT
THICKNESS CHECK
Chapter 3 Convenient Usage
ORIGIN SETUP
MEDIA THICKNESS = *.* mm
[ENT]
[ENT]
[ENT]
[ENT]
THICKNESS CHECK
CHECK START
** MOVING NOW **
3.0 mm PLEASE WAIT
3
3-5
