VLT HVAC Drive Programming Guide

5.1.16 16-** Data Readouts

Par. Parameter description
No. #
16-0* General Status
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference [%]
16-03 Status Word
16-05 Main Actual Value [%]
16-09 Custom Readout
16-1* Motor Status
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
16-13 Frequency
16-14 Motor Current
16-15 Frequency [%]
16-16 Torque [Nm]
16-17 Speed [RPM]
16-18 Motor Thermal
16-22 Torque [%]
16-26 Power Filtered [kW]
16-27 Power Filtered [hp]
16-3* Drive Status
16-30 DC Link Voltage
16-32 Brake Energy /s
16-33 Brake Energy /2 min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-36 Inv. Nom. Current
16-37 Inv. Max. Current
16-38 SL Controller State
16-39 Control Card Temp.
16-40 Logging Buffer Full
16-43 Timed Actions Status
16-49 Current Fault Source
16-5* Ref. & Feedb.
16-50 External Reference
16-52 Feedback [Unit]
16-53 Digi Pot Reference
16-54 Feedback 1 [Unit]
16-55 Feedback 2 [Unit]
16-56 Feedback 3 [Unit]
16-58 PID Output [%]
Default value
0 N/A
0.000 ReferenceFeedbackUnit
0.0 %
0 N/A
0.00 %
0.00 CustomReadoutUnit
0.00 kW
0.00 hp
0.0 V
0.0 Hz
0.00 A
0.00 %
0.0 Nm
0 RPM
0 %
0 %
0.000 kW
0.000 hp
0 V
0.000 kW
0.000 kW
0 °C
0 %
SR
SR
0 N/A
0 °C
[0] No
[0] Timed Actions Auto
0 N/A
0.0 N/A
0.000 ProcessCtrlUnit
0.00 N/A
0.000 ProcessCtrlUnit
0.000 ProcessCtrlUnit
0.000 ProcessCtrlUnit
0.0 %
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
5 Parameter Lists
4-set-up Change dur- Conver-
ing operation sion index
All set-ups FALSE 0
All set-ups FALSE -3
All set-ups FALSE -1
All set-ups FALSE 0
All set-ups FALSE -2
All set-ups FALSE -2
All set-ups FALSE 1
All set-ups FALSE -2
All set-ups FALSE -1
All set-ups FALSE -1
All set-ups FALSE -2
All set-ups FALSE -2
All set-ups FALSE -1
All set-ups FALSE 67
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE -3
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 0
All set-ups FALSE 100
All set-ups FALSE 0
All set-ups FALSE -2
All set-ups FALSE -2
All set-ups FALSE 0
All set-ups FALSE 100
All set-ups TRUE -
All set-ups TRUE -
All set-ups TRUE 0
All set-ups FALSE -1
All set-ups FALSE -3
All set-ups FALSE -2
All set-ups FALSE -3
All set-ups FALSE -3
All set-ups FALSE -3
All set-ups TRUE -1
Type
V2
Int32
Int16
V2
N2
Int32
Int32
Int32
5
Uint16
Uint16
Int32
N2
Int32
Int32
Uint8
Int16
Int32
Int32
Uint16
Uint32
Uint32
Uint8
Uint8
Uint32
Uint32
Uint8
Uint8
Uint8
Uint8
Uint8
Int16
Int32
Int16
Int32
Int32
Int32
Int16
291
