3 Parameter Description
9-22 Telegram Selection
Option:
[1]
Standard telegram 1
[101]
PPO 1
3
[102]
PPO 2
[103]
PPO 3
[104]
PPO 4
[105]
PPO 5
[106]
PPO 6
[107]
PPO 7
[108] *
PPO 8
[200]
Custom telegram 1
9-23 Parameters for Signals
Array [1000]
Option:
[0] *
None
[302]
Minimum Reference
[303]
Maximum Reference
[341]
Ramp 1 Ramp Up Time
[342]
Ramp 1 Ramp Down Time
[351]
Ramp 2 Ramp Up Time
[352]
Ramp 2 Ramp Down Time
[380]
Jog Ramp Time
[381]
Quick Stop Ramp Time
[411]
Motor Speed Low Limit [RPM]
[413]
Motor Speed High Limit [RPM]
[416]
Torque Limit Motor Mode
[417]
Torque Limit Generator Mode
[590]
Digital & Relay Bus Control
[593]
Pulse Out #27 Bus Control
[595]
Pulse Out #29 Bus Control
[597]
Pulse Out #X30/6 Bus Control
[653]
Terminal 42 Output Bus Control
[663]
Terminal X30/8 Output Bus Control
[890]
Bus Jog 1 Speed
[891]
Bus Jog 2 Speed
[894]
Bus Feedback 1
[895]
Bus Feedback 2
[896]
Bus Feedback 3
[1500]
Operating Hours
[1501]
Running Hours
[1502]
kWh Counter
118
Function:
Select a standard Profibus telegram configuration for the frequency converter, as an alternative to
using the freely configurable telegrams in par. 9-15
Read Configuration
.
Function:
This parameter contains a list of signals available for selection in par. 9-15
tion
PCD Read Configuration
and par. 9-16
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
®
VLT
HVAC Drive Programming Guide
PCD Write Configuration
and par. 9-16
PCD Write Configura-
.
