VLT
HVAC Drive Programming Guide
8-37 Maximum Inter-Char Delay
Range:
Application
[Application dependant]
dependent*
3.9.5 8-4* Telegram Selection
8-40 Telegram Selection
Option:
[1] *
Standard telegram 1
[101]
PPO 1
[102]
PPO 2
[103]
PPO 3
[104]
PPO 4
[105]
PPO 5
[106]
PPO 6
[107]
PPO 7
[108]
PPO 8
[200]
Custom telegram 1
8-42 PCD write configuration
Option:
[0]
None
[302]
Minimum Reference
[303]
Maximum Reference
[312]
Catch up/slow Down Value
[341]
Ramp 1 Ramp up Time
[342]
Ramp 1 Ramp Down Time
[351]
Ramp 2 Ramp up Time
[352]
Ramp 2 Ramp down Time
[380]
Jog Ramp Time
[381]
Quick Stop Ramp Time
[411]
Motor Speed Low Limit [RPM]
[412]
Motor Speed Low Limit [Hz]
[413]
Motor Speed High Limit [RPM]
[414]
Motor Speed High Limit [Hz]
[416]
Torque Limit Motor Mode
[417]
Torque Limit Generator Mode
[590]
Digital & Relay Bus Control
[593]
Pulse Out #27 Bus Control
[595]
Pulse Out #29 Bus Control
[597]
Pulse Out #X30/6 Bus Control
[653]
Terminal 42 Output Bus Control
[663]
Terminal X30/8 Bus Control
Function:
Specify the maximum permissible time interval between receipt of two bytes. This parameter acti-
vates time-out if transmission is interrupted.
Function:
Enables use of freely configurable telegrams or standard telegrams for the FC port.
Function:
Select the parameters to be assigned to PCD's telegrams. The number of available PCDs depends
on the telegram type. The values in PCD's will then be written to the selected parameters as data
values.
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
3 Parameter Description
3
107
