3 Parameter Description

21-42 Ext. 2 Integral Time

Range:
10000.00 [0.01 - 10000.00 s]
s*

21-43 Ext. 2 Differentation Time

Range:
3
0.00 s* [0.00 - 10.00 s]

21-44 Ext. 2 Dif. Gain Limit

Range:
5.0 N/A* [1.0 - 50.0 N/A]

3.19.7 21-5* Closed Loop 3 Ref/Fb

Configure Extended Closed Loop 3 Controller reference and feedback.
21-50 Ext. 3 Ref./Feedback Unit
Option:
[0]
[1] * %
[5] PPM
[10] 1/min
[11] RPM
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[75] mm Hg
[80] kW
198
Function:
Ext. 1 Integral Time
See par. 21-22 for details.
Function:
Ext. 1 Differentation Time
See par. 21-23
Function:
See par. 21-24 Ext. 1 Dif. Gain Limit
Function:
Ext. 1 Ref./Feedback Unit
See par. 21-10
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
®
VLT HVAC Drive Programming Guide
for details.
for details.
for details.
