3 Parameter Description

26-44 Terminal X42/7 Timeout Preset

Range:
0.00 %* [0.00 - 100.00 %]
3

3.24.7 26-5* Analog Out X42/9

Parameters for configuring the scaling and output function for analog output, terminal X42/9.

26-50 Terminal X42/9 Output

Option:
[0] * No operation
[100] Output freq. 0-100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[139] Bus ctrl.
[141] Bus ctrl t.o.

26-51 Terminal X42/9 Min. Scale

Range:
0.00 %* [0.00 - 200.00 %]
See principle graph for par. 6-51
260
Function:
Holds the preset level of terminal X42/7.
In case of a bus timeout and a timeout function is selected in par. 26-50
output will preset to this level.
Function:
Set the function of terminal X42/9.
: 0 - 100 Hz, (0-20 mA)
: Minimum reference - Maximum reference, (0-20 mA)
: -200% to +200% of par. 20-14
: 0 - Inverter Max. Current (par. 16-37
: 0 - Torque limit (par. 4-16
: 0 - Motor rated torque, (0-20 mA)
: 0 - Motor rated power, (0-20 mA)
: 0 - Speed High Limit (par. 4-13
Limit [Hz]
), (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
Function:
Scale the minimum output of the selected analog signal at terminal X42/9, as a percentage of the
maximum signal level. E.g. if a 0 V is desired at 25% of the maximum output value. Then programme
25%. Scaling values up to 100% can never be higher than the corresponding setting in
Terminal X42/9 Max. Scale
par. 26-52
Terminal 42 Output Min Scale
.
MG.11.C9.02 - VLT
®
VLT HVAC Drive Programming Guide
Maximum Reference/Feedb.
, (0-20 mA)
Inv. Max. Current
), (0-20 mA)
Torque Limit Motor Mode ), (0-20 mA)
Motor Speed High Limit [RPM]
.
® is a registered Danfoss trademark
Terminal X42/9 Output
the
Motor Speed High
and par. 4-14
