VLT HVAC Drive Programming Guide

24-90 Missing Motor Function

Option:
[0] * Off
[1] Warning

24-91 Missing Motor Coefficient 1

Range:
0.0000 N/ [-10.0000 - 10.0000 N/A]
A*
24-92 Missing Motor Coefficient 2
Range:
0.0000 N/ [-100.0000 - 100.0000 N/A]
A*
24-93 Missing Motor Coefficient 3
Range:
0.0000 N/ [-100.0000 - 100.0000 N/A]
A*
24-94 Missing Motor Coefficient 4
Range:
0.000 N/A* [-500.000 - 500.000 N/A]

24-95 Locked Rotor Function

Option:
[0] * Off
[1] Warning

24-96 Locked Rotor Coefficient 1

Range:
0.0000 N/ [-10.0000 - 10.0000 N/A]
A*
24-97 Locked Rotor Coefficient 2
Range:
0.0000 N/ [-100.0000 - 100.0000 N/A]
A*
24-98 Locked Rotor Coefficient 3
Range:
0.0000 N/ [-100.0000 - 100.0000 N/A]
A*
24-99 Locked Rotor Coefficient 4
Range:
0.000 N/A* [-500.000 - 500.000 N/A]
Function:
Select the action to be taken if the motor current is below the limit calculated as a function of the
output frequency. The function is used for detecting e.g. a missing motor in multi-motor applica-
tions.
Function:
Function:
Function:
Function:
Function:
Select the action to be taken if the motor current is above the limit calculated as a function of the
output frequency. The function is used for detecting e.g. a locked rotor in multi-motor applications.
Function:
Function:
Function:
Function:
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
3
239
