VLT HVAC Drive Programming Guide

16-86 FC Port REF 1

Range:
0 N/A* [-200 - 200 N/A]

3.16.9 16-9* Diagnosis Read-Outs

Parameters displaying alarm, warning and extended status words.

16-90 Alarm Word

Range:
0 N/A* [0 - 4294967295 N/A]
16-91 Alarm Word 2
Range:
0 N/A* [0 - 4294967295 N/A]

16-92 Warning Word

Range:
0 N/A* [0 - 4294967295 N/A]
16-93 Warning Word 2
Range:
0 N/A* [0 - 4294967295 N/A]
16-94 Ext. Status Word
Range:
0 N/A* [0 - 4294967295 N/A]
16-95 Ext. Status Word 2
Range:
0 N/A* [0 - 4294967295 N/A]
16-96 Maintenance Word
Range:
0 N/A* [0 - 4294967295 N/A]
Function:
View the two-byte Status word (STW) sent to the Bus-Master. Interpretation of the Status word
depends on the fieldbus option installed and the Control word profile selected in par. 8-10
Profile
.
Function:
View the alarm word sent via the serial communication port in hex code.
Function:
View the alarm word 2 sent via the serial communication port in hex code.
Function:
View the warning word sent via the serial communication port in hex code.
Function:
View the warning word 2 sent via the serial communication port in hex code.
Function:
Returns the extended status word sent via the serial communication port in hex code.
Function:
Returns the extended warning word 2 sent via the serial communication port in hex code.
Function:
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
