VLT HVAC Drive Programming Guide

23-63 Timed Period Start

Range:
Application [Application dependant]
dependent*
NB!
The frequency converter has no back up of the clock function and the set date/time will reset to default (2000-01-01 00:00) after a
power down unless a Real Time Clock module with back up is installed. Consequently the logging will be stopped until date/time is
readjusted in par. 0-70
properly, e.g. after a power down.
NB!
When mounting an Analog I/O MCB 109 option card, a battery back up of the date and time is included.

23-64 Timed Period Stop

Range:
Application [Application dependant]
dependent*
NB!
When mounting an Analog I/O MCB 109 option card, a battery back up of the date and time is included.

23-65 Minimum Bin Value

Range:
Application [Application dependant]
dependent*

23-66 Reset Continuous Bin Data

Option:
[0] * Do not reset
[1] Do reset
23-67 Reset Timed Bin Data
Option:
[0] * Do not reset
[1] Do reset
Function:
Set the date and time at which the Trending starts the update of the Timed Bin counters.
Date format will depend on setting in par. 0-71
par. 0-72 Time Format .
Date and Time Clock Fault
. In par. 0-79
Function:
Set the date and time at which the Trend Analyses must stop update of the Timed Bin counters.
Date format will depend on setting in par. 0-71
par. 0-72 Time Format .
Function:
Array with 10 elements ([0]-[9] below parameter number in display). Press OK and step between
▲
elements by means of
Set the minimum limit for each interval in par. 23-61
Data . Example: if selecting
based on the interval 0 - <12% and
Function:
Do reset
Select [1] to reset all values in par. 23-61
After pressing OK the setting of the parameter value will automatically change to
Function:
Do reset
Select [1] to reset all counters in par. 23-62
After pressing OK the setting of the parameter value will automatically change to
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
Date Format
it is possible to program for a Warning in case clock not has been set
Date Format
▼
and buttons on the LCP.
Continuous Bin Data
counter [1] and changing setting from 10% to 12%,
counter [1] on interval 12% - <20%.
Continuous Bin Data
Timed Bin Data
3 Parameter Description
, and time format on setting in
, and time format on setting in
Timed Bin
and par. 23-62
counter [0] will be
.
Do not reset
[0].
.
Do not reset [0].
3
