2 How to Programme
4.
Choose Application Settings with the [
5. Press [OK]
6. Press [OK] again for Fan Functions
7. Choose Broken Belt Function by pressing [OK]
2
▼
8.
With [ ] button, choose [2] Trip
The frequency converter will now trip if a broken fan-belt is detected.
Select [My Personal Menu] to display personal parameters:
Select [My Personal Menu] to display only the parameters, which have been pre-selected and programmed as personal parameters. For example, an AHU
or pump OEM may have pre-programmed personal parameters to be in My Personal Menu during factory commissioning to make on-site commissioning/
fine tuning simpler. These parameters are selected in par. 0-25
Select [Changes Made] to get information about:
• The last 10 changes. Use the up/down navigation keys to scroll between the last 10 changed parameters.
• The changes made since default setting.
Select [Loggings]:
to get information about the display line read-outs. The information is shown as graphs.
Only display parameters selected in par. 0-20
samples in the memory for later reference.

Quick Setup

Efficient Parameter Set-up for VLT HVAC Drive Applications:
The parameters can easily be set up for the vast majority of the VLT HVAC Drive applications only by using the [Quick Setup] option.
After pressing [Quick Menu], the different choices in the Quick Menu are listed. See also illustration 6.1 below and tables Q3-1 to Q3-4 in the follow-
Function Setups
ing section.
Example of using the Quick Setup option:
Assume you want to set the Ramp Down Time to 100 seconds!
1. Select [Quick Setup]. The first par. 0-01
▼
2.
Press [ ] repeatedly until par. 3-42
3. Press [OK]
◀
4.
Use the [ ] button to highlight the 3rd digit before the comma
5.
Change '0' to '1' by using the [
▶
6.
Use the [ ] button to highlight the digit '2'
7.
Change '2' to '0' with the [
8. Press [OK]
The new ramp-down time is now set to 100 seconds.
It is recommended to do the set-up in the order listed.
NB!
A complete description of the function is found in the parameter sections of this manual.
22
▼
] button
My Personal Menu
Display Line 1.1 Small
and par. 0-24
Language
in Quick Setup appears
Ramp 1 Ramp Down Time
▲
] button
▼
] button
MG.11.C9.02 - VLT
VLT
. Up to 20 different parameters can be programmed in this menu.
Display Line 3 Large
can be viewed. It is possible to store up to 120
appears with the default setting of 20 seconds
