Danfoss VLT Programming Manual page 37

®
VLT HVAC Drive Programming Guide
[39] Display Text 3
[89] Date and Time Readout
[953] Profibus Warning Word
[1005] Readout Transmit Error Counter
[1006] Readout Receive Error Counter
[1007] Readout Bus Off Counter
[1013] Warning Parameter
[1115] LON Warning Word
[1117] XIF Revision
[1118] LonWorks Revision
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference [Unit]
[1602] * Reference [%]
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor Current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1622] Torque [%]
[1626] Power Filtered [kW]
[1627] Power Filtered [hp]
[1630] DC Link Voltage
[1632] Brake Energy /s
Enables an individual text string to be written, for display in the LCP or to be read via serial com-
munication.
Displays the current date and time.
Displays Profibus communication warnings.
View the number of CAN control transmission errors since the last power-up.
View the number of CAN control receipt errors since the last power-up.
View the number of Bus Off events since the last power-up.
View a DeviceNet-specific warning word. One separate bit is assigned to every warning.
Shows the LON-specific warnings.
Shows the version of the external interface file of the Neuron C chip on the LON option.
Shows the software version of the application program of the Neuron C chip on the LON option.
View the number of running hours of the motor.
View the mains power consumption in kWh.
View the Control Word sent from the frequency converter via the serial communication port in hex
code.
Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in selected
unit.
Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in percent.
Present status word
View the two-byte word sent with the Status word to the bus Master reporting the Main Actual Value.
View the user-defined readouts as defined in par. 0-30
Readout Min Value and par. 0-32 Custom Readout Max Value
Actual power consumed by the motor in kW.
Actual power consumed by the motor in HP.
Voltage supplied to the motor.
Motor frequency, i.e. the output frequency from the frequency converter in Hz.
Phase current of the motor measured as effective value.
Motor frequency, i.e. the output frequency from the frequency converter in percent.
Present motor load as a percentage of the rated motor torque.
Motor speed reference. Actual speed will depend on slip compensation being used (compensation
set in par. 1-62 Slip Compensation ). If not used, actual speed will be the value read in the display
minus motor slip.
Thermal load on the motor, calculated by the ETR function. See also parameter group 1-9* Motor
Temperature.
Shows the actual torque produced, in percentage.
Intermediate circuit voltage in the frequency converter.
Present brake power transferred to an external brake resistor.
Stated as an instantaneous value.
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
Custom Readout Unit Custom
, par. 0-31
.
3
37
