[74] Logic Rule 4
[75] Logic Rule 5
[80] SL Digital Output A
[81] SL Digital Output B
[82] SL Digital Output C
[83] SL Digital Output D
[84] SL Digital Output E
[85] SL Digital Output F

3.9.4 8-3* FC Port Settings

Parameters for configuring the FC Port.

8-30 Protocol

Option:
[0] * FC
[1] FC MC
[2] Modbus RTU
[3] Metasys N2
[4] FLN
[9] FC Option
[20] LEN
If Logic Rule 4 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
If Logic Rule 5 is evaluated as TRUE, the input will go high. Otherwise, it will be low.
SL Controller Action. The input will go high whenever the Smart Logic Action [38] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [32] Set dig. out. A low is
executed.
SL Controller Action. The input will go high whenever the Smart Logic Action [39] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [33] Set dig. out. A low is
executed.
SL Controller Action. The input will go high whenever the Smart Logic Action [40] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [34] Set dig. out. A low is
executed.
SL Controller Action. The input will go high whenever the Smart Logic Action [41] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [35] Set dig. out. A low is
executed.
SL Controller Action. The input will go high whenever the Smart Logic Action [42] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [36] Set dig. out. A low is
executed.
SL Controller Action. The input will go high whenever the Smart Logic Action [43] Set dig. out. A
high is executed. The input will go low whenever the Smart Logic Action [37] Set dig. out. A low is
executed
Function:
Protocol selection for the integrated FC (standard) Port (RS485) on the control card.
Parameter group 8-7* is only visible when FC Option [9] is chosen.
Communication according to the FC Protocol as described in the
RS485 Installation and Set-up
.
Same as FC [0] but to be used when downloading SW to the frequency converter or uploading dll
file (covering information regarding parameters available in the frequency converter and their inter-
dependencies) to Motion Control Tool MCT10.
Communication according to the Modbus RTU protocol as described in the
Guide, RS485 Installation and Set-up
Communication protocol. The N2 software protocol is designed to be general in nature in order to
accommodate the unique properties each device may have. Please see separate manual
Drive Metasys MG.11.Gx.yy
.
To be used when a gateway is connected to the integrated RS485 port, e.g. the BACnet gateway.
Following changes will take place:
-Address for the FC port will be set to 1 and par. 8-31
the gateway on the network, e.g. BACnet.
VLT HVAC Drive BACnet, MG.11.Dx.yy
Please see separate manual
-Baud rate for the FC port will be set to a fixed value (115.200 Baud) and par. 8-32
now used to set the baud rate for the network port (e.g. BACnet) on the gateway.
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
VLT HVAC Drive Design Guide,
.
Address
, is now used to set the address for
.
3
VLT HVAC Drive Design
VLT HVAC
Baud Rate , is
