VLT HVAC Drive Programming Guide

26-40 Terminal X42/7 Output

Option:
[0] * No operation
[100] Output freq. 0-100
[101] Reference Min-Max
[102] Feedback +-200%
[103] Motor cur. 0-Imax
[104] Torque 0-Tlim
[105] Torque 0-Tnom
[106] Power 0-Pnom
[107] Speed 0-HighLim
[113] Ext. Closed Loop 1
[114] Ext. Closed Loop 2
[115] Ext. Closed Loop 3
[139] Bus ctrl.
[141] Bus ctrl t.o.

26-41 Terminal X42/7 Min. Scale

Range:
0.00 %* [0.00 - 200.00 %]

26-42 Terminal X42/7 Max. Scale

Range:
100.00 %* [0.00 - 200.00 %]
Terminal 42 Output Max Scale
See principle graph for par. 6-52

26-43 Terminal X42/7 Bus Control

Range:
0.00 %* [0.00 - 100.00 %]
Function:
Set the function of terminal X42/7 as an analog voltage output.
: 0 - 100 Hz, (0-20 mA)
: Minimum reference - Maximum reference, (0-20 mA)
Maximum Reference/Feedb.
: -200% to +200% of par. 20-14
: 0 - Inverter Max. Current (par. 16-37
: 0 - Torque limit (par. 4-16 Torque Limit Motor Mode
: 0 - Motor rated torque, (0-20 mA)
: 0 - Motor rated power, (0-20 mA)
: 0 - Speed High Limit (par. 4-13
Limit [Hz] ), (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
: 0 - 100%, (0-20 mA)
Function:
Scale the minimum output of the selected analog signal at terminal X42/7, as a percentage of the
maximum signal level. E.g. if a 0 V (or 0 Hz) is desired at 25% of the maximum output value. Then
programme 25%. Scaling values up to 100% can never be higher than the corresponding setting
Terminal X42/7 Max. Scale
in par. 26-42
Terminal 42 Output Min Scale
See principle graph for par. 6-51
Function:
Scale the maximum output of the selected analog signal at terminal X42/7. Set the value to the
maximum value of the voltage signal output. Scale the output to give a voltage lower than 10V at
full scale; or 10V at an output below 100% of the maximum signal value. If 10V is the desired output
current at a value between 0-100% of the full-scale output, programme the percentage value in the
parameter, i.e. 50% = 10V. If a voltage between 0 and 10V is desired at maximum output, calculate
the percentage as follows:
( )
10 V
x
desired maximum voltage
i.e.
V
10
V
5 : × 100 % = 200 %
V
5
.
Function:
Holds the level of terminal X42/7 if controlled by bus.
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
, (0-20 mA)
Inv. Max. Current ), (0-20 mA)
), (0-20 mA)
Motor Speed High Limit [RPM] and par. 4-14
.
.
100 %
3
Motor Speed High
259
