3 Parameter Description
16-72 Counter A
Range:
0 N/A* [-2147483648 - 2147483647 N/A]
16-73 Counter B
3
Range:
0 N/A* [-2147483648 - 2147483647 N/A]
16-75 Analog In X30/11
Range:
0.000 N/A* [-20.000 - 20.000 N/A]
16-76 Analog In X30/12
Range:
0.000 N/A* [-20.000 - 20.000 N/A]
16-77 Analog Out X30/8 [mA]
Range:
0.000 N/A* [0.000 - 30.000 N/A]
3.16.8 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control words.

16-80 Fieldbus CTW 1

Range:
0 N/A* [0 - 65535 N/A]

16-82 Fieldbus REF 1

Range:
0 N/A* [-200 - 200 N/A]

16-84 Comm. Option STW

Range:
0 N/A* [0 - 65535 N/A]
16-85 FC Port CTW 1
Range:
0 N/A* [0 - 65535 N/A]
170
Function:
View the present value of Counter A. Counters are useful as comparator operands, see
Comparator Operand
par. 13-10 .
The value can be reset or changed either via digital inputs (parameter group 5-1*) or by using an
SL Controller Action
SLC action (par. 13-52
Function:
View the present value of Counter B. Counters are useful as comparator operands
Comparator Operand
(par. 13-10 ).
The value can be reset or changed either via digital inputs (parameter group 5-1*) or by using an
SL Controller Action
SLC action (par. 13-52
Function:
View the actual value at input X30/11 of MCB 101.
Function:
View the actual value at input X30/12 of MCB 101.
Function:
View the actual value at input X30/8 in mA.
Function:
View the two-byte Control word (CTW) received from the Bus-Master. Interpretation of the Control
word depends on the fieldbus option installed and the Control word profile selected in
Control Profile
par. 8-10 .
For more information please refer to the relevant fieldbus manual.
Function:
View the two-byte word sent with the control word form the Bus-Master to set the reference value.
For more information please refer to the relevant fieldbus manual.
Function:
View the extended fieldbus comm. option status word.
For more information please refer to the relevant fieldbus manual.
Function:
View the two-byte Control word (CTW) received from the Bus-Master. Interpretation of the control
word depends on the fieldbus option installed and the Control word profile selected in
par. 8-10 Control Profile .
