3 Parameter Description
[9927] HS Temp. (PC8)
NB!
Please consult the

0-21 Display Line 1.2 Small

3
Select a variable for display in line 1, middle position.
Option:
[1614] * Motor Current

0-22 Display Line 1.3 Small

Select a variable for display in line 1, right position.
Option:
[1610] * Power [kW]

0-23 Display Line 2 Large

Select a variable for display in line 2.
Option:
[1613] * Frequency

0-24 Display Line 3 Large

Select a variable for display in line 3.
Option:
[1502] * kWh Counter
0-25 My Personal Menu
Array [20]
Range:
Application [0 - 9999 N/A]
dependent*
3.2.5 0-3*LCP Custom Readout
It is possible to customize the display elements for various purposes: *Custom Readout. Value proportional to speed (Linear, squared or cubed depending
on unit selected in par. 0-30
Custom Readout
The calculated value to be displayed is based on settings in par. 0-30
par. 0-32 Custom Readout Max Value
40
VLT HVAC Drive Programming Guide, MG.11.CX.YY
Function:
The options are the same as those listed in par. 0-20
Function:
The options are the same as those listed in par. 0-20
Function:
The options are the same as those listed in par. 0-20
Function:
The options are the same as those listed in par. 0-20
Function:
Define up to 20 parameters to appear in the Q1 Personal Menu, accessible via the [Quick Menu]
key on the LCP. The parameters will be displayed in the Q1 Personal Menu in the order they are
programmed into this array parameter. Delete parameters by setting the value to '0000'.
For example, this can be used to provide quick, simple access to just one or up to 20 parameters
which require changing on a regular basis (e.g. for plant maintenance reasons) or by an OEM to
enable simple commissioning of their equipment.
Custom Readout Unit ) *Display Text. Text string stored in a parameter.
, par. 4-13 Motor Speed High Limit [RPM]
MG.11.C9.02 - VLT
VLT
for detailed information.
Display Line 1.1 Small
Display Line 1.1 Small
Display Line 1.1 Small
Display Line 1.1 Small
Custom Readout Unit , par. 0-31 Custom Readout Min Value
, par. 4-14 Motor Speed High Limit [Hz]
® is a registered Danfoss trademark
®
HVAC Drive Programming Guide
.
.
.
.
(linear only),
and actual speed.
