No. Description
66 Heat sink Temperature Low
67 Option Configuration has Changed
68 Safe Stop Activated
69 Pwr. Card Temp
70 Illegal FC configuration
71 PTC 1 Safe Stop
72 Dangerous Failure
73 Safe Stop Auto Restart
76 Power Unit Setup
79 Illegal PS config
80 Drive Initialized to Default Value
91 Analog input 54 wrong settings
92 NoFlow
93 Dry Pump
94 End of Curve
95 Broken Belt
96 Start Delayed
97 Stop Delayed
98 Clock Fault
201 Fire M was Active
202 Fire M Limits Exceeded
203 Missing Motor
204 Locked Rotor
243 Brake IGBT
244 Heatsink temp
245 Heatsink sensor
246 Pwr.card supply
247 Pwr.card temp
248 Illegal PS config
250 New spare parts
251 New Type Code
Table 4.2: Alarm/Warning code list
(X) Dependent on parameter
1) Can not be Auto reset via par. 14-20
A trip is the action when an alarm has appeared. The trip will coast the motor and can be reset by pressing the reset button or make a reset by a digital
input (parameter group 5-1* [1]). The original event that caused an alarm cannot damage the frequency converter or cause dangerous conditions. A trip
lock is an action when an alarm occurs, which may cause damage to frequency converter or connected parts. A Trip Lock situation can only be reset by
a power cycling.
LED indication
Warning
Alarm
Trip locked
Table 4.3: LED Indication
Warning
X
X
X
X
X
X
X
X
X
X
X
X
Reset Mode
yellow
flashing red
yellow and red
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
Alarm/Trip Alarm/Trip Lock
X
1)
X
X X
X
1)
X
1)
X
X X
X
X
X
X
X
X
X
X X
X X
X X
X X
X X
X
X X
