3 Parameter Description
[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3

3-17 Reference 3 Source

Option:
3
[0] * No function
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3

3-19 Jog Speed [RPM]

Range:
Application [Application dependant]
dependent*
3.5.3 3-4* Ramp 1
Configure the ramp parameter, ramping times, for each of the two ramps (par. 3-4* and par. 3-5*).
66
Function:
Select the reference input to be used for the third reference signal. par. 3-15
par. 3-16 Reference 2 Source and par. 3-17
ence signals. The sum of these reference signals defines the actual reference.
This parameter cannot be adjusted while the motor is running.
Function:
Enter a value for the jog speed n , which is a fixed output speed. The frequency converter runs
JOG
at this speed when the jog function is activated. The maximum limit is defined in par. .
See also par. 3-80 Jog Ramp Time .
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
®
VLT HVAC Drive Programming Guide
Reference 1 Source
Reference 3 Source define up to three different refer-
,
