VLT HVAC Drive Programming Guide
This parameter cannot be adjusted while the motor is running. Same options and functions as par. 5-6*.
[0] * No operation

5-62 Pulse Output Max Freq #27

Set the maximum frequency for terminal 27, corresponding to the output variable selected in par. 5-60
This parameter cannot be adjusted while the motor is running.
Range:
5000 Hz* [0 - 32000 Hz]

5-63 Terminal 29 Pulse Output Variable

Select the variable for viewing on the terminal 29 display.
This parameter cannot be adjusted while the motor is running. Same options and functions as par. 5-6*.
Option:
[0] * No operation

5-65 Pulse Output Max Freq #29

Set the maximum frequency for terminal 29 corresponding to the output variable set in par. 5-63
This parameter cannot be adjusted while the motor is running.
Range:
5000 Hz* [0 - 32000 Hz]

5-66 Terminal X30/6 Pulse Output Variable

Select the variable for read-out on terminal X30/6.
This parameter cannot be adjusted while the motor is running.
This parameter is active when option module MCB 101 is installed in the frequency converter.
Same options and functions as par. group 5-6*.
Option:
[0] * No operation
[45] Bus ctrl.
[48] Bus ctrl., timeout
[51] MCO controlled
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[119] Torque % lim
5-68 Pulse Output Max Freq #X30/6
Select the maximum frequency on terminal X30/6 referring to the output variable in par. 5-66
cannot be adjusted while the motor is running.
This parameter is active when option module MCB 101 is mounted in the frequency converter.
Range:
Application [0 - 32000 Hz]
dependent*
Function:
Function:
Function:
Function:
Function:
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
Terminal 27 Pulse Output Variable
Terminal 29 Pulse Output Variable
Terminal X30/6 Pulse Output Variable
.
3
.
. This parameter
91
