3 Parameter Description

26-01 Terminal X42/3 Mode

Option:
3
[1] * Voltage
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]

26-02 Terminal X42/5 Mode

Option:
[1] * Voltage
[2] Pt 1000 [°C]
[3] Pt 1000 [°F]
[4] Ni 1000 [°C]
[5] Ni 1000 [°F]
3.24.3 26-1* Analog Input X42/1
Parameters for configuring the scaling and limits for analog input, terminal X42/1.

26-10 Terminal X42/1 Low Voltage

Range:
0.07 V* [Application dependant]

26-11 Terminal X42/1 High Voltage

Range:
10.00 V* [Application dependant]
26-14 Term. X42/1 Low Ref./Feedb. Value
Range:
0.000 N/A* [-999999.999 - 999999.999 N/A]
256
Function:
Terminal X42/3 can be programmed as an analog input accepting a voltage or input from either Pt
1000 or Ni 1000 temperature sensors. Select the desired mode.
Pt 1000, [2] and Ni 1000, [4] if operating in Celsius - Pt 1000, [3] and Ni 1000, [5] if operating in
Fahrenheit.
Notice: If the input is not in use, it must be set for Voltage!
If set for temperature and used as feed back, the unit must be set for either Celsius or Fahrenheit
(par. 20-12 Reference/Feedback Unit
Feedback Unit Ext. 3 Ref./Feedback Unit
or par. 21-50
Function:
Terminal X42/5 can be programmed as an analog input accepting a voltage or input from either Pt
1000 (1000 Ω at 0° C) or Ni 1000 (1000 Ω at 0° C) temperature sensors. Select the desired mode.
Pt 1000, [2] and Ni 1000, [4] if operating in Celsius - Pt 1000, [3] and Ni 1000, [5] if operating in
Fahrenheit.
Notice: If the input is not in use, it must be set for Voltage!
If set for temperature and used as feed back, the unit must be set for either Celsius or Fahrenheit
Reference/Feedback Unit
(par. 20-12
Feedback Unit Ext. 3 Ref./Feedback Unit
or par. 21-50
Function:
Enter the low voltage value. This analog input scaling value should correspond to the low reference/
Term. X42/1 Low Ref./Feedb. Value
feedback value set in par. 26-14
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par. 26-15
Function:
Enter the analog input scaling value that corresponds to the low voltage value set in
par. 26-10 Terminal X42/1 Low Voltage
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
®
VLT HVAC Drive Programming Guide
, par. 21-10 Ext. 1 Ref./Feedback Unit
).
Ext. 1 Ref./Feedback Unit
, par. 21-10
).
.
Term. X42/1 High Ref./Feedb. Value
.
, par. 21-30 Ext. 2 Ref./
Ext. 2 Ref./
, par. 21-30
.
