VLT HVAC Drive Programming Guide
[1663] Terminal 54 Switch Setting
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1667] Pulse Input #29 [Hz]
[1668] Pulse Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1696] Maintenance Word
[1830] Analog Input X42/1
[1831] Analog Input X42/3
[1832] Analog Input X42/5
[1833] Analog Out X42/7 [V]
[1834] Analog Out X42/9 [V]
[1835] Analog Out X42/11 [V]
[1850] Sensorless Readout [unit]
9-18 Node Address
Range:
126 N/A* [Application dependant]
Function:
Enter the station address in this parameter or alternatively in the hardware switch. In order to adjust
Node Address
the station address in par. 9-18
all switches set to 'on'). Otherwise this parameter will display the actual setting of the switch.
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
, the hardware switch must be set to 126 or 127 (i.e.
