3 Parameter Description

16-37 Inv. Max. Current

Range:
Application
[0.01 - 10000.00 A]
dependent*

16-38 SL Controller State

Range:
3
0 N/A*
[0 - 100 N/A]
16-39 Control Card Temp.
Range:
0 C*
[0 - 100 C]
16-40 Logging Buffer Full
Option:
[0] *
No
[1]
Yes

3.16.5 16-43 Timed Actions Status

16-43 Timed Actions Status
View the timed actions mode.
Option:
[0] *
Timed Actions Auto
[1]
Timed Actions Disabled
[2]
Constant On Actions
[3]
Constant Off Actions
16-49 Current Fault Source
Range:
0 N/A*
[0 - 8 N/A]
After a short circuit alarm (imax2) or over current alarm (imax1 or phase imbalance) this will contain the power card number associated with the alarm.
It only holds one number so it will indicate the highest priority power card number (master first). The value will persist on power cycle but if a new alarm
occurs it will be overwritten with the new power card number (even if it a lower priority number). The value will only be cleared when the alarm log is
cleared (i.e. a 3-finger reset would reset the readout to 0).
3.16.6 16-5* Ref. & Feedb.
Parameters for reporting the reference and feedback input.
16-50 External Reference
Range:
0.0 N/A*
[-200.0 - 200.0 N/A]
166
Function:
View the inverter maximum current, which should match the nameplate data on the connected
motor. The data are used for calculation of torque, motor protection, etc.
Function:
View the state of the event under execution by the SL controller.
Function:
View the temperature on the control card, stated in °C.
Function:
View whether the logging buffer is full (see parameter group 15-1*). The logging buffer will never
Logging Mode
be full when par. 15-13
Function:
Function:
Value indicates source of current fault, including: short circuit, over current and phase imbalance
(from left): [1-4] Inverter, [5-8] Rectifier, [0] No fault recorded
Function:
View the total reference, the sum of digital, analog, preset, bus and freeze references, plus catch-
up and slow-down.
MG.11.C9.02 - VLT
®
is a registered Danfoss trademark
®
VLT
HVAC Drive Programming Guide
Log always
is set to
[0].
