VLT HVAC Drive Programming Guide

26-15 Term. X42/1 High Ref./Feedb. Value

Range:
100.000 N/ [-999999.999 - 999999.999 N/A]
A*

26-16 Term. X42/1 Filter Time Constant

Range:
0.001 s* [0.001 - 10.000 s]

26-17 Term. X42/1 Live Zero

Option:
[0] Disabled
[1] * Enabled

3.24.4 26-2* Analog Input X42/3

Parameters for configuring the scaling and limits for analog input, terminal X42/3.
26-20 Terminal X42/3 Low Voltage
Range:
0.07 V* [Application dependant]
26-21 Terminal X42/3 High Voltage
Range:
10.00 V* [Application dependant]
26-24 Term. X42/3 Low Ref./Feedb. Value
Range:
0.000 N/A* [-999999.999 - 999999.999 N/A]
26-25 Term. X42/3 High Ref./Feedb. Value
Range:
100.000 N/ [-999999.999 - 999999.999 N/A]
A*
26-26 Term. X42/3 Filter Time Constant
Range:
0.001 s* [0.001 - 10.000 s]
Function:
Enter the analog input scaling value that corresponds to the high voltage value set in
Terminal X42/1 High Voltage
par. 26-11
Function:
Enter the time constant. This is a first-order digital low pass filter time constant for suppressing
noise in terminal X42/1. A high time constant value improves dampening but also increases the time
delay through the filter. This parameter cannot be adjusted while the motor is running.
Function:
This parameter makes it possible to enable the Live Zero monitoring. E.g. where the analog input
is a part of the frequency converter control, rather than being used as part of a decentral I/O system,
such as a Building Management System.
Function:
Enter the low voltage value. This analog input scaling value should correspond to the low reference/
feedback value set in par. 26-24 Term. X42/3 Low Ref./Feedb. Value
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par. 26-25
Function:
Enter the analog input scaling value that corresponds to the low voltage value set in
Terminal X42/3 Low Voltage
par. 26-20
Function:
Enter the analog input scaling value that corresponds to the high voltage value set in
Terminal X42/3 High Voltage
par. 26-21
Function:
Enter the time constant. This is a first-order digital low pass filter time constant for suppressing
noise in terminal X42/3. A high time constant value improves dampening but also increases the time
delay through the filter. This parameter cannot be adjusted while the motor is running.
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
3 Parameter Description
.
.
Term. X42/3 High Ref./Feedb. Value
.
.
