3 Parameter Description
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
3
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt

13-52 SL Controller Action

Array [20]
Option:
[0] * Disabled
[1] No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
[15] Select preset ref 5
[16] Select preset ref 6
[17] Select preset ref 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
144
Function:
Select the action corresponding to the SLC event. Actions are executed when the corresponding
SL Controller Event
event (defined in par. 13-51
available for selection:
Changes the active set-up (par. 0-10
Changes the active set-up (par. 0-10
Changes the active set-up (par. 0-10
Changes the active set-up (par. 0-10
with other set-up commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 0.
Selects preset reference 1.
Selects preset reference 2.
Selects preset reference 3.
Selects preset reference 4.
Selects preset reference 5.
Selects preset reference 6.
Selects preset reference 7. If the active preset reference is changed, it will merge with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects ramp 1
Selects ramp 2
Issues a start command to the frequency converter.
MG.11.C9.02 - VLT ® is a registered Danfoss trademark
®
VLT HVAC Drive Programming Guide
) is evaluated as true. The following actions are
Active Set-up ) to '1'.
Active Set-up
) to '2'.
Active Set-up
) to '3'.
Active Set-up
) to '4'. If the set-up is changed, it will merge
