VLT® Soft Starter MCD 600
Operating Guide

8.4 Soft Starter Status LEDs

Ready Run
Illustration 26: Status LEDs on LCP
Table 27: LED Descriptions
LED name On
Ready The motor is stopped and the soft
starter is ready to start.
Run The motor is in run state (receiving full
voltage).
Trip The soft starter has tripped.
Local The soft starter is controlled via a re-
mote LCP.
If all LEDs are off, the soft starter is not receiving control voltage.

8.5 Displays

8.5.1 Soft Starter Information

At power-up, the soft starter information screen shows details of the soft starter rating, software versions, and serial number.
WELCOME
1
01.01/01.00/01.00
MCD6-0069B-T5-S1-CV2
2
Illustration 27: Welcome Screen
1 Software versions: User interface, motor control, remote LCP (remote LCP software version is only shown when a
remote LCP is connected)
2 Model code: Current rating, mains voltage, frame size, control voltage

8.5.2 Configurable Feedback Screens

Select which information to show on the display. To switch between the 2 configurable screens, press [▵] and [▿].

8.5.3 Operating Feedback Screens

The operating feedback screens show the motor running current on the top half of the screen. To select which information is shown
on the lower half, press [▵] and [▿].
58 | Danfoss A/S © 2020.12
Trip Local
Flashing
The motor is stopped and the soft starter is not ready to start:
•
•
•
The motor is starting or stopping.
The soft starter is in warning state.
–
Waiting for the restart delay (parameter 5-16 Restart Delay).
The thermal models indicate that the soft starter and/or motor are too
hot to start safely.
The reset input (RESET, COM+) is open.
LCP and Feedback
AQ262141844215en-000401 / 175R1174
