Server Node Diagnostic Tools
Diagnostic Tool
Oracle ILOM
Preboot Menu
System indicators
and LEDs
Power-On Self-Test
(POST)
U-Boot
UEFI Diagnostics
(for Oracle Database
Appliance X4-2/
X5-2 and X6 series)
Pc-Check (for Oracle
Database Appliance
X3-2 and Oracle
98 Oracle Database Appliance Service Manual • June 2017
What It Does
firmware component versions are supported
to work together. Patches are available
through My Oracle Support.
The Oracle ILOM preboot menu is a utility
that can be used to fix problems with Oracle
ILOM that cannot be fixed while it is
running. It allows you to interrupt the Oracle
ILOM boot process, configure settings, then
continue booting Oracle ILOM. Among
other things, it allows you to reset the Oracle
ILOM root password to factory defaults,
restore Oracle ILOM access to the serial port.
Provides at-a-glance status of the system and
its components.
Tests core components of system: CPUs,
memory, and motherboard I/O bridge
integrated circuits.
Initializes and test aspects of the SP prior to
booting Oracle ILOM. Tests SP memory, SP,
network devices and I/O devices.
UEFI-based utility that tests and detect
problems on all processor, memory, disk
drives, and network ports. It is used on newer
Oracle systems.
DOS-based utility that tests all motherboard
components (CPU, memory, and I/O), ports,
and slots.
Where to Find Information
Refer to the appropriate Oracle x86 Servers
Diagnostics Guide based on your appliance's
supported version of Oracle ILOM.
http://www.oracle.com/goto/
x86AdminDiag/docs
■ Chapter 1, "Overview of System Status
Indicators and LEDs"
■ You can also use Oracle ILOM to check
server node indicator status. Refer to the
appropriate Oracle Integrated Lights Out
Manager (ILOM) Documentation Library
based on your appliance's supported
version of Oraclel ILOM.
http://www.oracle.com/goto/ILOM/
docs
For Oracle Database Appliance X3-2/X4-2/
X5-2 and X6-2 series, refer to the appropriate
Oracle x86 Servers Diagnostics Guide based
on your appliance's supported version of
Oracle ILOM.
http://www.oracle.com/goto/
x86AdminDiag/docs
For the Oracle Database Appliance Version
1, see:
■ "Default BIOS Power-On Self-Test
(POST) Events" on page 213
■ "BIOS POST F1 and F2
Errors" on page 214
Refer to the appropriate Oracle x86 Servers
Diagnostics Guide based on your appliance's
supported version of Oracle ILOM.
http://www.oracle.com/goto/
x86AdminDiag/docs
Refer to the appropriate Oracle x86 Servers
Diagnostics Guide based on your appliance's
supported version of Oracle ILOM.
http://www.oracle.com/goto/
x86AdminDiag/docs
Refer to the appropriate Oracle x86 Servers
Diagnostics Guide based on your appliance's
supported version of Oracle ILOM.
